Запчасти Komatsu WA500-1LC FIG. A-A ПРИВОД ВЕНТИЛЯТОРА ДВИГАТЕЛЬ

1

1238 060 H1

BOLT

SN: A60001-UP-UP

3шт.

2

1238 064 H1

BOLT

SN: A60001-UP-UP

2шт.

3

1267 655 H1

NUT, JAM - HEAVY HEX

SN: A60001-UP-UP

1шт.

4

1238 105 H1

WASHER, LOCK

SN: A60001-UP-UP

3шт.

5

1238 207 H1

WASHER, PLAIN

SN: A60001-UP-UP

2шт.

6

1238 400 H1

BOLT

SN: A60001-UP-UP

1шт.

7

1238 826 H1

BRACKET, FAN

SN: A60001-UP-UP

1шт.

8

1238 926 H1

BRACE, FAN

SN: A60001-UP-UP

1шт.

9

1239 331 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

10

1239 430 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

11

1295 855 H1

BELT, FAN

SN: A60001-UP-UP

2шт.

|$11

1295 856 H91

HUB, FAN

SN: A60001-UP-UP

1шт.

12

1238 124 H1

PLUG, PIPE

SN: A60001-UP-UP

2шт.

13

1240 087 H1

BOLT

SN: A60001-UP-UP

2шт.

14

1238 297 H1

NUT, LOCK

SN: A60001-UP-UP

1шт.

15

1238 329 H1

SEAL - O-RING

SN: A60001-UP-UP

1шт.

16

1238 564 H1

SEAL - OIL

SN: A60001-UP-UP

1шт.

17

1238 565 H1

COVER - FAN HUB

SN: A60001-UP-UP

1шт.

18

1295 857 H1

COVER - FAN HUB

SN: A60001-UP-UP

1шт.

19

1238 924 H1

SPACER, BEARING

SN: A60001-UP-UP

1шт.

20

1238 925 H1

SPACER, BEARING

SN: A60001-UP-UP

1шт.

21

1239 000 H1

RING, RETAINING

SN: A60001-UP-UP

1шт.

22

1239 001 H1

BEARING, ROLLER

SN: A60001-UP-UP

2шт.

23

1239 262 H1

WASHER, PLAIN

SN: A60001-UP-UP

1шт.

24

1239 790 H1

PULLEY, FAN

SN: A60001-UP-UP

1шт.

25

1295 858 H1

SPINDLE, FAN

SN: A60001-UP-UP

1шт.
