Запчасти Komatsu WA500-1LC FIG. A-A КОРОМЫСЛО КОЖУХ COVER ДВИГАТЕЛЬ

1

25 522 R1

NUT - HEAVY HEX

SN: A60001-UP-UP

1шт.

2

102 644 H45

HOSE - PLAIN

SN: A60001-UP-UP

1шт.

3

1296 850 H1

CLIP

SN: A60001-UP-UP

1шт.

4

1296 849 H1

TUBE, VENT

SN: A60001-UP-UP

1шт.

5

1239 165 H1

CLAMP - SPRING HOSE

SN: A60001-UP-UP

2шт.

6

1239 733 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

15шт.

7

1295 580 H1

GASKET - ROCKER LEVER COVER

SN: A60001-UP-UP

3шт.

8

1238 963 H91

BREATHER, CRANKCASE

SN: A60001-UP-UP

1шт.

9

1239 116 H1

COVER, ROCKER LEVER - WITHOUT BREATHER

SN: A60001-UP-UP

2шт.

10

1295 836 H1

COVER, ROCKER LEVER - WITH BREATHER

SN: A60001-UP-UP

1шт.

11

1238 189 H1

BRACE - TUBE

SN: A60001-UP-UP

1шт.

|$11

1238 101 H1

WASHER, LOCK - 5/16 IN.

SN: A60001-UP-UP

1шт.

|$12

1238 081 H1

NUT, HEAVY HEX - 5/16-18 IN.

SN: A60001-UP-UP

1шт.

12

120 382

WASHER, LOCK

SN: A60001-UP-UP

1шт.

13

1238 001 H1

BOLT

SN: A60001-UP-UP

1шт.

14

1238 099 H1

WASHER, PLAIN

SN: A60001-UP-UP

1шт.
