Запчасти Komatsu WA500-1LC FIG. A-A ВОДЯНОЙ КОЛЛЕКТОР ДВИГАТЕЛЬ

1

1239 287 H1

MANIFOLD, WATER

SN: A60001-UP-UP

1шт.

2

1239 513 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.

3

1239 328 H1

MANIFOLD, WATER

SN: A60001-UP-UP

1шт.

4

1239 300 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.

5

343 909 R1

O-RING

SN: A60001-UP-UP

1шт.

6

1240 426 H1

CLAMP - HOSE

SN: A60001-UP-UP

2шт.

7

1258 637 H1

TUBE - WATER BYPASS

SN: A60001-UP-UP

1шт.

8

1238 893 H1

CLAMP - TUBE

SN: A60001-UP-UP

1шт.

9

1239 481 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

1шт.

10

1295 936 H1

HOSE - PLAIN

SN: A60001-UP-UP

1шт.

11

1240 052 H1

O-RING

SN: A60001-UP-UP

4шт.

12

1238 261 H1

CONNECTION - WATER BYPASS

SN: A60001-UP-UP

2шт.

13

140 483 H

BOLT - WITH WASHER

SN: A60001-UP-UP

12шт.

14

1239 503 H1

SEAL, GROMMET

SN: A60001-UP-UP

6шт.

15

1238 260 H1

MANIFOLD, WATER

SN: A60001-UP-UP

1шт.

16

1239 159 H1

PLUG, PIPE

SN: A60001-UP-UP

4шт.

17

1239 160 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.
