Запчасти Komatsu WA500-1LC FIG. A-A ВОДН. ВЫПУСКН. СОЕДИН-Е ДВИГАТЕЛЬ

1

1238 500 H1

SEAL - THERMOSTAT

SN: A60001-UP-UP

1шт.

2

1295 937 H1

HOUSING - THERMOSTAT

SN: A60001-UP-UP

1шт.

3

1239 212 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

4

1239 420 H1

GASKET - WATER OUTLET CONNECTION

SN: A60001-UP-UP

1шт.

5

1239 405 H1

CONNECTION - WATER OUTLET

SN: A60001-UP-UP

1шт.

6

1238 601 H2

THERMOSTAT

SN: A60001-UP-UP

1шт.

7

1238 823 H1

GASKET - THERMOSTAT HOUSING

SN: A60001-UP-UP

1шт.

8

1239 213 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

4шт.

9

1239 300 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.

10

1267 662 H1

COUPLING - PLAIN HOSE

SN: A60001-UP-UP

1шт.
