Запчасти Komatsu WA500-1LC FIG. A-A ВОДЯНАЯ ПОМПА ДВИГАТЕЛЬ

|$0

1241 836 H1

PULLEY - WATER PUMP IDLER

SN: A60001-UP-UP

1шт.

1

1238 076 H1

NUT - HEAVY HEX

SN: A60001-UP-UP

1шт.

2

1238 132 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.

3

1238 054 H1

RING, RETAINING

SN: A60001-UP-UP

1шт.

4

1252 527 H1

SHAFT, IDLER

SN: A60001-UP-UP

1шт.

5

1238 822 H2

SPACER - MOUNTING

SN: A60001-UP-UP

1шт.

6

1238 872 H1

WASHER, PLAIN

SN: A60001-UP-UP

1шт.

7

1238 903 H1

PULLEY, IDLER

SN: A60001-UP-UP

1шт.

8

1295 729 H1

BEARING, BALL

SN: A60001-UP-UP

1шт.

9

1238 481 H1

BOLT

SN: A60001-UP-UP

1шт.

|$10

1258 150 H91

PUMP, WATER

SN: A60001-UP-UP

1шт.

10

1295 831 H1

GASKET - WATER PUMP

SN: A60001-UP-UP

1шт.

|$12

NSS

PUMP, WATER

SN: A60001-UP-UP

1шт.

11

1238 124 H1

PLUG, PIPE

SN: A60001-UP-UP

2шт.

12

1238 054 H1

RING, RETAINING

SN: A60001-UP-UP

1шт.

13

1239 300 H1

PLUG, PIPE

SN: A60001-UP-UP

1шт.

14

1238 540 H1

SPACER, BEARING

SN: A60001-UP-UP

1шт.

15

1258 152 H1

SHAFT - WATER PUMP

SN: A60001-UP-UP

1шт.

16

1239 805 H1

BODY - WATER PUMP

SN: A60001-UP-UP

1шт.

17

1295 729 H1

BEARING, BALL

SN: A60001-UP-UP

2шт.

18

1238 995 H1

IMPELLER - WATER PUMP

SN: A60001-UP-UP

1шт.

19

1252 822 H91

PULLEY - WATER PUMP

SN: A60001-UP-UP

1шт.

20

1239 655 H2

SEAL - WATER PUMP

SN: A60001-UP-UP

1шт.

21

343 909 R1

SEAL, O-RING

SN: A60001-UP-UP

1шт.

22

1239 506 H1

GASKET - CONNECTION

SN: A60001-UP-UP

1шт.

23

1239 264 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

24

1239 263 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

4шт.

25

1238 934 H1

BELT, V-RIBBED - WATER PUMP

SN: A60001-UP-UP

1шт.

|$28

1295 832 H91

KIT, WATER PUMP REPAIR - MINOR

SN: A60001-UP-UP

1шт.

|$29

1295 833 H91

KIT, WATER PUMP REPAIR - MAJOR

SN: A60001-UP-UP

1шт.

|$30

-1шт.

|$31

F1 - INCLUDED IN MINOR WATER PUMP REPAIR KIT.

-1шт.

|$32

-1шт.

|$33

-1шт.

|$34

F2 - INCLUDED IN MAJOR WATER PUMP REPAIR KIT.

-1шт.

|$35

-1шт.
