Запчасти Komatsu WA500-1LC FIG. A-8A ТОПЛИВН. ОТСЕКАЮЩ. КЛАПАН ДВИГАТЕЛЬ

|$0

1239 688 H92

VALVE - FUEL SHUTOFF

SN: A60001-UP-UP

1шт.

1

1241 506 H1

SOLENOID, FUEL SHUTOFF VALVE - 24 V

SN: A60001-UP-UP

1шт.

|$2

1238 258 H91

BODY - SHUTOFF VALVE

SN: A60001-UP-UP

1шт.

2

1238 255 H1

BODY - SHUTOFF VALVE

SN: A60001-UP-UP

1шт.

3

1238 256 H1

KNOB

SN: A60001-UP-UP

1шт.

4

1294 098 H1

O-RING

SN: A60001-UP-UP

1шт.

5

1238 976 H1

SHAFT - SHUTOFF VALVE

SN: A60001-UP-UP

1шт.

6

117 737

SHIELD - SHUTOFF VALVE

SN: A60001-UP-UP

1шт.

7

117 741

SPRING, VALVE

SN: A60001-UP-UP

1шт.

8

117 738

O-RING

SN: A60001-UP-UP

1шт.

9

1238 507 H1

BOLT - 3/16-24 X 5/8 IN.

SN: A60001-UP-UP

4шт.

10

1239 609 H1

DISC, VALVE

SN: A60001-UP-UP

1шт.

11

6216-14-4810

PLUG, PIPE - 1/8 NPT

SN: A60001-UP-UP

1шт.

12

1238 069 H1

BOLT - 1/4-20 X 1 3/4 IN.

SN: A60001-UP-UP

2шт.

13

1238 480 H1

WASHER, LOCK - 1/4 IN.

SN: A60001-UP-UP

2шт.

14

117 740

O-RING

SN: A60001-UP-UP

1шт.

15

1240 005 H1

WASHER, PLAIN - 1/4 IN.

SN: A60001-UP-UP

2шт.
