Запчасти Komatsu WA500-1LC FIG. A-7A ВОЗД. УПРАВЛ-Е ПОДАЧ. ТОПЛИВА (AFC) ASSEMBLY ДВИГАТЕЛЬ

|$0

1296 745 H91

AIR FUEL CONTROL ASSEMBLY

SN: A60001-UP-UP

1шт.

|$1

1296 748 H91

BARREL AND PLUNGER

SN: A60001-UP-UP

1шт.

1

NSS

PLUNGER - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

2

NSS

BARREL - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

3

1239 303 H1

DIAPHRAGM

SN: A60001-UP-UP

1шт.

4

1296 749 H1

COVER - FUEL CONTROL

SN: A60001-UP-UP

1шт.

5

1239 283 H1

BOLT - FILLISTER HEAD

SN: A60001-UP-UP

1шт.

6

1296 750 H1

NUT, LOCK

SN: A60001-UP-UP

1шт.

7

1296 751 H1

PISTON - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

8

1296 752 H1

PISTON - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

9

1294 101 H1

O-RING

SN: A60001-UP-UP

2шт.

10

1294 108 H1

O-RING

SN: A60001-UP-UP

1шт.

11

1294 109 H1

O-RING

SN: A60001-UP-UP

1шт.

12

1296 753 H1

WASHER, PLAIN

SN: A60001-UP-UP

2шт.

13

1296 754 H1

SHIM - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

|$15

1239 017 H1

SHIM - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

|$16

1296 755 H1

SHIM - AIR FUEL CONTROL

SN: A60001-UP-UP

2шт.

|$17

1296 756 H1

SHIM - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

|$18

1296 757 H1

SHIM - AIR FUEL CONTROL

SN: A60001-UP-UP

1шт.

14

1239 397 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

15

1238 053 H1

RING, RETAINING

SN: A60001-UP-UP

1шт.

16

1296 758 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

17

1240 070 H1

BOLT - FILLISTER HEAD

SN: A60001-UP-UP

2шт.

18

1238 182 H1

SCREW, SET - SOCKET HEAD

SN: A60001-UP-UP

2шт.

19

1296 759 H1

COVER, PROTECTIVE

SN: A60001-UP-UP

1шт.

20

1296 760 H1

RETAINER, SPRING

SN: A60001-UP-UP

1шт.

21

1296 761 H1

NUT, LOCK

SN: A60001-UP-UP

2шт.

22

1296 762 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

23

1239 335 H91

VALVE, CHECK

SN: A60001-UP-UP

1шт.

|$29

-1шт.

|$30

F1 - USED WITH FUEL PUMP 3893950 CAL. 865.

-1шт.

|$31

-1шт.
