Запчасти Komatsu WA500-1LC FIG. A-A РЕГУЛЯТОР SPRING PACK ДВИГАТЕЛЬ

|$0

1241 685 H91

COVER - GOVERNOR SPRING PACK

SN: A60001-UP-UP

1шт.

1

1241 687 H1

COVER - GOVERNOR SPRING PACK

SN: A60001-UP-UP

1шт.

2

1241 688 H91

PLUG - THREADED

SN: A60001-UP-UP

1шт.

3

1239 669 H1

O-RING

SN: A60001-UP-UP

1шт.

4

1240 060 H1

GASKET - GOVERNOR SPRING PACK

SN: A60001-UP-UP

1шт.

|$5

1239 734 H91

PACK, IDLE

SN: A60001-UP-UP

1шт.

5

1239 705 H1

GUIDE - IDLE SPRING PLUNGER

SN: A60001-UP-UP

1шт.

6

1239 628 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

7

1240 063 H1

SCREW - KNURLED

SN: A60001-UP-UP

1шт.

8

1239 369 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

6шт.

9

1238 053 H1

RING, RETAINING

SN: A60001-UP-UP

2шт.

10

1239 406 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

11

1239 370 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

12

1296 764 H1

PLUNGER - IDLE SPRING

SN: A60001-UP-UP

1шт.

13

1239 067 H1

SEAL, WIRE

SN: A60001-UP-UP

2шт.

14

1238 629 H1

SPACER, MOUNTING

SN: A60001-UP-UP

1шт.

15

1240 062 H1

WASHER, PLAIN

SN: A60001-UP-UP

1шт.

16

1240 064 H1

SHIM - 0.020 IN. (0.508 MM)

SN: A60001-UP-UP

-2шт.

|$18

1240 065 H1

SHIM - 0.010 IN. (0.254 MM)

SN: A60001-UP-UP

-2шт.

|$19

1240 066 H1

SHIM - 0.005 IN. (0.127 MM)

SN: A60001-UP-UP

-2шт.

|$20

1238 449 H1

SHIM - 0.007 IN. (0.178 MM)

SN: A60001-UP-UP

-2шт.

|$21

1238 511 H1

SHIM - 0.007 IN. (0.178 MM)

SN: A60001-UP-UP

-2шт.

17

1296 765 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

|$23

1239 452 H91

COVER - GOVERNOR SPRING PACK

SN: A60001-UP-UP

1шт.

18

1239 341 H91

COVER - GOVERNOR SPRING PACK

SN: A60001-UP-UP

1шт.

19

1239 230 H1

BUSHING

SN: A60001-UP-UP

2шт.

20

1240 048 H1

O-RING

SN: A60001-UP-UP

2шт.

21

1238 182 H1

SCREW - ADJUSTING

SN: A60001-UP-UP

2шт.

22

1240 080 H1

SCREW - SET

SN: A60001-UP-UP

1шт.

23

1239 231 H1

SHAFT, THROTTLE

SN: A60001-UP-UP

1шт.

24

1240 084 H1

STOP - THROTTLE SHAFT

SN: A60001-UP-UP

1шт.

25

1239 233 H1

SEAL, DUST

SN: A60001-UP-UP

2шт.

26

1238 184 H1

NUT - FUEL PUMP ADJUSTING

SN: A60001-UP-UP

2шт.

27

1250 262 H1

NUT, HEX

SN: A60001-UP-UP

2шт.

28

1238 192 H1

WASHER, PLAIN

SN: A60001-UP-UP

4шт.

|$35

1237 957 H91

PACK, IDLING

SN: A60001-UP-UP

1шт.

29

1240 082 H1

PLUNGER, GOVERNOR

SN: A60001-UP-UP

1шт.

30

1240 083 H1

RING, RETAINING

SN: A60001-UP-UP

1шт.

31

1240 075 H1

GUIDE, SPRING

SN: A60001-UP-UP

1шт.

32

1238 357 H1

SPRING, COMPRESSION

SN: A60001-UP-UP

1шт.

33

1240 077 H1

SHIM - 0.020 IN. (0.508 MM)

SN: A60001-UP-UP

-2шт.

|$41

1240 078 H1

SHIM - 0.010 IN. (0.254 MM)

SN: A60001-UP-UP

-2шт.

|$42

1240 079 H1

SHIM - 0.005 IN. (0.127 MM)

SN: A60001-UP-UP

-2шт.

34

1241 572 H1

SPRING, GOVERNOR

SN: A60001-UP-UP

1шт.

35

1240 085 H1

PLUNGER - THROTTLE LEVER

SN: A60001-UP-UP

1шт.

36

1240 060 H1

GASKET - SPRING PACK

SN: A60001-UP-UP

1шт.

37

1239 369 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

6шт.
