Запчасти Komatsu WA500-1LC FIG. A-A ТОПЛИВН. НАСОС ПРИВОД ДВИГАТЕЛЬ

|$0

1239 665 H92

GEAR ASSEMBLY - FUEL PUMP

SN: A60001-UP-UP

1шт.

|$1

1296 792 H91

ASSEMBLY - HOUSING AND COVER

SN: A60001-UP-UP

1шт.

1

NSS

HOUSING - FUEL PUMP GEAR

SN: A60001-UP-UP

1шт.

2

NSS

COVER - FUEL PUMP GEAR

SN: A60001-UP-UP

1шт.

3

1240 073 H1

BOLT - SOCKET HEAD

SN: A60001-UP-UP

2шт.

4

1240 059 H1

WASHER, PLAIN

SN: A60001-UP-UP

2шт.

5

1238 480 H1

WASHER, LOCK

SN: A60001-UP-UP

2шт.

6

1239 657 H1

DOWEL, RING

SN: A60001-UP-UP

1шт.

7

1238 185 H1

GASKET - FUEL PUMP

SN: A60001-UP-UP

1шт.

|$9

1239 352 H91

GEAR AND SHAFT

SN: A60001-UP-UP

1шт.

8

1238 216 H1

GEAR - FUEL PUMP

SN: A60001-UP-UP

1шт.

9

1238 138 H1

SHAFT - FUEL PUMP DRIVE

SN: A60001-UP-UP

1шт.

|$12

1239 432 H91

GEAR AND SHAFT

SN: A60001-UP-UP

1шт.

10

1238 216 H1

GEAR - FUEL PUMP

SN: A60001-UP-UP

1шт.

11

1238 438 H1

SHAFT - FUEL PUMP

SN: A60001-UP-UP

1шт.

12

1239 985 H1

DOWEL, PIN

SN: A60001-UP-UP

2шт.

13

1239 660 H91

VALVE, CHECK

SN: A60001-UP-UP

1шт.

14

1239 669 H1

O-RING

SN: A60001-UP-UP

1шт.

15

1250 120 H1

VALVE - PRESSURE REGULATOR

SN: A60001-UP-UP

1шт.

16

1239 661 H91

PLUG - THREADED

SN: A60001-UP-UP

1шт.

17

1239 669 H1

O-RING

SN: A60001-UP-UP

1шт.

18

1239 529 H2

GASKET - FUEL PUMP

SN: A60001-UP-UP

1шт.

N/I

1240 073 H1

BOLT - SOCKET HEAD

SN: A60001-UP-UP

4шт.

N/I

1238 480 H1

WASHER, LOCK

SN: A60001-UP-UP

4шт.
