Запчасти Komatsu WA500-1LC FIG. T-A КОВШ TEETH - БОЛТ-ON ТИП РАБОЧЕЕ ОБОРУДОВАНИЕ

1

425-70-13222

TOOTH, L.H.

SN: A60001-UP-UP

1шт.

|$2

OR

-1шт.

1

425-842-1120

TOOTH, L.H. - LIMESTONE

SN: A60001-UP-UP

1шт.

|$6

OR

-1шт.

1

425-70-13232

TOOTH, R.H.

SN: A60001-UP-UP

1шт.

|$10

OR

-1шт.

1

425-842-1130

TOOTH, R.H. - LIMESTONE

SN: A60001-UP-UP

1шт.

2

425-70-13212

TOOTH - CENTER

SN: A60001-UP-UP

6шт.

3

425-847-1211

ADAPTER - L.H.

SN: A60001-UP-UP

1шт.

|$16

OR

-1шт.

3

425-847-1221

ADAPTER - R.H.

SN: A60001-UP-UP

1шт.

4

425-847-1191

ADAPTER - CENTER

SN: A60001-UP-UP

6шт.

5

426-847-1110

TIP, TOOTH

SN: A60001-UP-UP

8шт.

6

426-847-1130

PIN - TOOTH TIP MOUNTING

SN: A60001-UP-UP

8шт.

7

02091-11610

BOLT, CORNER TEETH MOUNTING - BOTTOM

SN: A60001-UP-UP

4шт.

8

02290-11625

NUT

SN: A60001-UP-UP

4шт.

9

425-70-13250

SHIM, CORNER TEETH -0.020 IN. (0.50 MM)

SN: A60001-UP-UP

4шт.

|$25

425-70-13260

SHIM, CORNER TEETH -0.063 IN. (1.60 MM)

SN: A60001-UP-UP

2шт.

10

02091-11600

BOLT, SIDE - CORNER TEETH MOUNTING

SN: A60001-UP-UP

2шт.

11

01643-32780

WASHER

SN: A60001-UP-UP

2шт.

12

02290-11625

NUT

SN: A60001-UP-UP

2шт.

13

02091-11610

BOLT - CENTER TEETH MOUNTING

SN: A60001-UP-UP

18шт.

14

02290-11625

NUT

SN: A60001-UP-UP

18шт.

15

155-70-14240

SHIM, CENTER TEETH -0.020 IN. (0.50 MM)

SN: A60001-UP-UP

12шт.

|$32

155-70-14230

SHIM, CENTER TEETH -0.063 IN. (1.60 MM)

SN: A60001-UP-UP

6шт.
