Запчасти Komatsu WA500-1LC FIG. S-A КОЛЕСА И ШИНЫ - 9. IN. X IN. ПОДВЕСКА И КОЛЕСА

1

TIRE - 29.5 X 25, 22 PLY, L3 RATING,GOODYEAR

SN: A60001-UP-UP

4шт.

|$2

OR

-1шт.

1

TIRE - 29.5 X 25, 22 PLY, L3 RATING,FIRESTONE

SN: A60001-UP-UP

4шт.

|$6

OR

-1шт.

1

TIRE - 29.5 X 25, 22 PLY, L4 RATING,GOODYEAR

SN: A60001-UP-UP

4шт.

|$10

OR

-1шт.

1

TIRE - 29.5 X 25, 28 PLY, L4 RATING,GOODYEAR

SN: A60001-UP-UP

4шт.

|$14

OR

-1шт.

1

TIRE - 29.5 R25 XHA 1 STAR, RADIALMICHELIN

SN: A60001-UP-UP

4шт.

|$17

425-W31-1101

WHEEL ASSEMBLY - 29.5 X 25

SN: A60001-UP-UP

4шт.

2

425-W31-1111

BASE, RIM

SN: A60001-UP-UP

1шт.

3

425-W31-1120

FLANGE, SIDE

SN: A60001-UP-UP

2шт.

4

425-W31-1130

BAND, BEAD SEAT

SN: A60001-UP-UP

1шт.

5

566-W31-1140

RING, LOCK

SN: A60001-UP-UP

1шт.

6

425-30-12240

DRIVER

SN: A60001-UP-UP

1шт.

7

566-30-11660

O-RING

SN: A60001-UP-UP

1шт.

|$24

09280-10020

VALVE ASSEMBLY

SN: A60001-UP-UP

1шт.

8

09283-00000

SEAT, VALVE

SN: A60001-UP-UP

1шт.

9

09280-10130

STEM, VALVE

SN: A60001-UP-UP

1шт.

10

09281-00041

CORE, VALVE

SN: A60001-UP-UP

1шт.

11

09282-00022

CAP

SN: A60001-UP-UP

1шт.

|$29

-1шт.

|$30

F1 - PURCHASE LOCALLY.

-1шт.

|$32

-1шт.

|$33

F2 - IF USED OR REQUIRED.

-1шт.

|$34

-1шт.

|$35

F-3 - TO CHANGE TIRES, SEE PARTS AND SERVICE NEWS A940041 FOR JACKING- UP PROCEDURE

-1шт.

|$36

-1шт.
