Запчасти Komatsu WA500-1LC FIG. A-A РЫЧАГ КОРОМЫСЛА И КОЖУХ ДВИГАТЕЛЬ

|$0

1241 831 H91

HOUSING ASSEMBLY - ROCKER LEVER

SN: A60001-UP-UP

3шт.

1

1239 794 H1

HOUSING - ROCKER LEVER

SN: A60001-UP-UP

1шт.

2

1239 736 H1

PLUG, O-RING

SN: A60001-UP-UP

2шт.

3

1238 406 H1

SCREW, SET - SOCKET HEAD

SN: A60001-UP-UP

1шт.

4

1239 737 H1

SHAFT - ROCKER LEVER

SN: A60001-UP-UP

1шт.

5

1239 823 H2

O-RING

SN: A60001-UP-UP

2шт.

6

1237 968 H91

LEVER - ROCKER

SN: A60001-UP-UP

2шт.

7

1238 293 H1

BUSHING

SN: A60001-UP-UP

1шт.

8

1238 077 H1

NUT - HEXAGON

SN: A60001-UP-UP

1шт.

9

1295 828 H1

ASSEMBLY, SCREW - ADJUSTING

SN: A60001-UP-UP

1шт.

10

1238 820 H1

RIVET

SN: A60001-UP-UP

1шт.

11

1237 967 H91

LEVER - ROCKER

SN: A60001-UP-UP

2шт.

12

1238 293 H1

BUSHING, LEVER

SN: A60001-UP-UP

1шт.

13

1238 077 H1

NUT - HEXAGON

SN: A60001-UP-UP

1шт.

14

1295 828 H1

ASSEMBLY, SCREW - ADJUSTING

SN: A60001-UP-UP

1шт.

15

1238 820 H1

RIVET, BLIND

SN: A60001-UP-UP

1шт.

16

1237 901 H91

LEVER - ROCKER

SN: A60001-UP-UP

2шт.

17

1238 939 H1

BUSHING

SN: A60001-UP-UP

1шт.

18

1238 529 H1

SOCKET - ROCKER LEVER

SN: A60001-UP-UP

1шт.

19

1238 077 H1

NUT - HEXAGON

SN: A60001-UP-UP

1шт.

20

1238 405 H1

SCREW, SET - SLOTTED HEAD

SN: A60001-UP-UP

1шт.

21

1239 208 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

6шт.

22

1239 381 H1

GASKET - ROCKER LEVER HOUSING

SN: A60001-UP-UP

1шт.
