Запчасти Komatsu WA500-1LC FIG. A-A ПОРШЕНЬ И ШАТУН ДВИГАТЕЛЬ

|$0

1239 305 H91

ROD ASSEMBLY - ENGINE CONNECTING

SN: A60001-UP-UP

6шт.

1

NSS

ROD - CONNECTING

SN: A60001-UP-UP

1шт.

2

1295 487 H1

BOLT - CONNECTING ROD

SN: A60001-UP-UP

2шт.

3

1238 506 H1

BUSHING

SN: A60001-UP-UP

1шт.

4

1240 051 H1

DOWEL

SN: A60001-UP-UP

2шт.

5

1238 897 H1

BEARING, CONNECTING ROD - STANDARD

SN: A60001-UP-UP

2шт.

|$6

1251 788 H1

BEARING, CONNECTING ROD - 0.010 IN. (0.254 MM) OVERSIZE

SN: A60001-UP-UP

2шт.

|$7

1251 789 H1

BEARING, CONNECTING ROD - 0.020 IN. (0.508 MM) OVERSIZE

SN: A60001-UP-UP

2шт.

|$8

1251 790 H1

BEARING, CONNECTING ROD - 0.030 IN. (0.762 MM) OVERSIZE

SN: A60001-UP-UP

2шт.

|$9

1251 791 H1

BEARING, CONNECTING ROD - 0.040 IN. (1.018 MM) OVERSIZE

SN: A60001-UP-UP

2шт.

6

1238 522 H1

PIN - PISTON

SN: A60001-UP-UP

1шт.

|$11

1295 918 H91

PISTON KIT, ENGINE

SN: A60001-UP-UP

6шт.

7

NSS

PISTON, ENGINE

SN: A60001-UP-UP

1шт.

8

1238 434 H1

RING, RETAINING

SN: A60001-UP-UP

2шт.

|$14

1250 685 H91

RING SET - PISTON

SN: A60001-UP-UP

6шт.

9

1238 938 H1

RING, PISTON - COMPRESSION

SN: A60001-UP-UP

1шт.

10

1238 923 H1

RING, PISTON - COMPRESSION

SN: A60001-UP-UP

1шт.

11

1295 919 H1

RING, PISTON - COMPRESSION

SN: A60001-UP-UP

1шт.

12

1238 951 H1

RING, PISTON - OIL

SN: A60001-UP-UP

1шт.
