Запчасти Komatsu WA500-1LC FIG. A-A КОЛЕНВАЛ ДВИГАТЕЛЬ

1

1238 831 H1

KEY

SN: A60001-UP-UP

1шт.

2

1239 316 H1

GEAR - CRANKSHAFT

SN: A60001-UP-UP

1шт.

3

1249 776 H91

CRANKSHAFT, ENGINE

SN: A60001-UP-UP

1шт.

4

1239 717 H1

DOWEL - RING

SN: A60001-UP-UP

7шт.

|$4

1239 951 H91

BEARING SET, MAIN - STANDARD

SN: A60001-UP-UP

1шт.

5

1239 421 H1

BEARING, MAIN - UPPER 1, 3 AND 5

SN: A60001-UP-UP

3шт.

6

1239 422 H1

BEARING, MAIN - LOWER 1, 3 AND 5

SN: A60001-UP-UP

3шт.

7

1239 423 H1

BEARING, MAIN - UPPER 2, 4 AND 6

SN: A60001-UP-UP

3шт.

8

1239 424 H1

BEARING, MAIN - LOWER 2, 4 AND 6

SN: A60001-UP-UP

3шт.

9

1239 425 H1

BEARING, MAIN - UPPER 7

SN: A60001-UP-UP

1шт.

10

1239 426 H1

BEARING, MAIN - LOWER 7

SN: A60001-UP-UP

1шт.

11

1295 568 H1

BEARING - THRUST

SN: A60001-UP-UP

4шт.

12

1295 824 H1

LOCKPLATE

SN: A60001-UP-UP

14шт.

|$13

1251 784 H1

BEARING SET, MAIN - 0.010 IN. (0.254 MM) OVERSIZE

SN: A60001-UP-UP

1шт.

|$14

1251 785 H1

BEARING SET, MAIN - 0.020 IN. (0.508 MM) OVERSIZE

SN: A60001-UP-UP

1шт.

|$15

1251 786 H1

BEARING SET, MAIN - 0.030 IN. (0.762 MM) OVERSIZE

SN: A60001-UP-UP

1шт.

|$16

1251 787 H1

BEARING SET, MAIN - 0.040 IN. (1.016 MM) OVERSIZE

SN: A60001-UP-UP

1шт.
