Запчасти Komatsu WA500-1LC FIG. K7-A КАБИНА - MODEL NOS. CD И CJ - ОТОПИТЕЛЬ - ОБОГРЕВАТЕЛЬ. CМАСЛ. ASSEMBLY КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

1

425-963-AB90

COIL - HEATER

SN: A60016-UP-UP

1шт.

2

425-963-AA40

VALVE - WATER

SN: A60016-UP-UP

1шт.

3

425-963-AA80

FITTING - 90 DEGREE

SN: A60016-UP-UP

2шт.

4

425-963-AD40

CABLE ASSEMBLY - WATER VALVE

SN: A60016-UP-UP

1шт.

5

HOSE, HEATER COIL TO WATER VALVE -4 IN. (102 MM)

SN: A60016-UP-UP

1шт.

6

HOSE, SPLICER FITTING TO HEATER COIL - 15.5 IN. (394 MM)

SN: A60016-UP-UP

1шт.

7

HOSE, WATER VALVE TO SPLICER FITTING -22 IN. (559 MM)

SN: A60016-UP-UP

1шт.

8

425-963-A870

CLAMP, HOSE

SN: A60016-UP-UP

6шт.

9

425-963-AA20

FITTING, SPLICER

SN: A60016-UP-UP

2шт.

10

INSULATION - 3 IN. (76 MM)

SN: A60016-UP-UP

2шт.

11

425-963-A850

BOLT, TORX TRUSS - 10-32 X 1/2

SN: A60016-UP-UP

4шт.

12

425-963-A680

COVER - COIL WELDMENT

SN: A60016-UP-UP

1шт.

13

425-963-AE20

KNOB

SN: A60016-UP-UP

1шт.

|$13

425-963-AF20

INSULATION, BULK - 6 IN. (152 MM)

SN: A60016-UP-UP

-2шт.

|$14

364 359 C1

HOSE, BULK

SN: A60016-UP-UP

-2шт.

|$15

-1шт.

|$16

F1 - CUT TO FIT FROM BULK HOSE.

-1шт.

|$17

-1шт.

|$18

-1шт.

|$19

F2 - CUT TO FIT FROM BULK INSULATION.

-1шт.

|$20

-1шт.
