Запчасти Komatsu WA500-1LC FIG. K7-A КАБИНА - MODEL NO. CB - КОНДИЦ. ВОЗДУХА - EVAPORATOR И ОБОГРЕВАТЕЛЬ. CМАСЛ. КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

AIR CONDITIONER ASSEMBLY(SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

1

425-963-1650

EVAPORATOR

SN: A60001-UP-UP

1шт.

2

425-963-1710

TUBE, LIQUID - TO RECEIVER

SN: A60001-UP-UP

1шт.

3

425-963-1720

TUBE, SUCTION - FROM COMPRESSOR

SN: A60001-UP-UP

1шт.

4

425-963-2180

VALVE - EXPANSION

SN: A60001-UP-UP

1шт.

5

425-963-1890

SWITCH - LOW-PRESSURE

SN: A60001-UP-UP

1шт.

6

425-963-1910

SWITCH - HIGH-PRESSURE

SN: A60001-UP-UP

1шт.

7

425-963-2230

CLIP - HOLDING

SN: A60001-UP-UP

1шт.

8

425-963-2240

CLAMP

SN: A60001-UP-UP

1шт.

9

COIL ASSEMBLY - HEATER (SEE FIG. K0714-01A0)

SN: A60001-UP-UP

1шт.

10

HOSE - SHUTOFF VALVE TO HEATER COIL (SEE FIG. K0714-01A0)

SN: A60001-UP-UP

1шт.

11

HOSE - HEATER COIL TO RADIATOR (SEE FIG. K0714-01A0)

SN: A60001-UP-UP

1шт.

12

425-963-1840

VALVE - HEATER SHUTOFF

SN: A60001-UP-UP

1шт.

13

425-963-1950

CLAMP - HOSE

SN: A60001-UP-UP

3шт.

14

425-963-2290

PIPE

SN: A60001-UP-UP

2шт.

15

425-963-2310

HOSE - RADIATOR HOSE TO VALVE

SN: A60001-UP-UP

1шт.

16

425-963-2320

CLAMP - HOSE

SN: A60001-UP-UP

3шт.

|$17

-1шт.

|$19

-1шт.
