Запчасти Komatsu WA500-1LC FIG. K7-A КАБИНА - MODEL NO. CB - ОТОПИТЕЛЬ - УПРАВЛ-ЕS И ПАНЕЛЬ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

418-T42-1111

HEATER UNIT

SN: A60001-UP-UP

1шт.

|$1

COIL, HEATER (SEE FIG. K0714-01A0)

SN: A60001-UP-UP

1шт.

1

418-T42-1131

CASE ASSEMBLY

SN: A60001-UP-UP

1шт.

2

COVER ASSEMBLY (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

3

418-T42-1150

CASE ASSEMBLY

SN: A60001-UP-UP

1шт.

4

PACKING (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

2шт.

5

DAMPER ASSEMBLY (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

6

SHAFT (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

7

LEVER - CONTROL (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

8

425-963-2190

INSERT

SN: A60001-UP-UP

2шт.

9

425-963-2210

BUSHING

SN: A60001-UP-UP

1шт.

10

418-T42-1141

COVER ASSEMBLY

SN: A60001-UP-UP

1шт.

11

COVER - CONTROL (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

12

425-963-2260

SWITCH - HEATER BLOWER

SN: A60001-UP-UP

1шт.

13

425-963-1780

LEVER ASSEMBLY - HEATER CONTROLS

SN: A60001-UP-UP

1шт.

14

418-T42-1120

PANEL - HEATER CONTROLS

SN: A60001-UP-UP

1шт.

15

CLAMP (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

4шт.

16

425-963-1850

KNOB

SN: A60001-UP-UP

1шт.

17

425-963-1860

KNOB

SN: A60001-UP-UP

2шт.

18

425-963-2170

GROMMET

SN: A60001-UP-UP

1шт.

19

CLAMP (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

4шт.

20

425-963-2280

CABLE

SN: A60001-UP-UP

1шт.

21

425-963-1960

GROMMET

SN: A60001-UP-UP

1шт.

22

425-963-1970

GROMMET

SN: A60001-UP-UP

1шт.

23

CABLE (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

24

SHAFT (SEE FIG. K0713-01A0)

SN: A60001-UP-UP

1шт.

25

425-963-2220

CLAMP

SN: A60001-UP-UP

1шт.

26

425-963-2120

GROMMET

SN: A60001-UP-UP

1шт.

27

425-963-2130

GROMMET

SN: A60001-UP-UP

1шт.

28

DAMPER ASSEMBLY (SEE FIG. K0710-01A0)

SN: A60001-UP-UP

1шт.

|$30

-1шт.

|$32

-1шт.
