Запчасти Komatsu WA500-1LC FIG. A-A КАРТЕР МАХОВИКА ДВИГАТЕЛЬ

1

1295 861 H1

SEAL, OIL

SN: A60001-UP-UP

1шт.

2

1295 862 H1

COVER, REAR

SN: A60001-UP-UP

1шт.

3

1240 055 H1

COVER - ACCESS HOLE

SN: A60001-UP-UP

1шт.

4

1239 014 H1

SCREW, METAL - SELF-TAPPING

SN: A60001-UP-UP

2шт.

5

1238 100 H1

WASHER, LOCK

SN: A60001-UP-UP

3шт.

6

1238 363 H1

BOLT - TWELVE POINT

SN: A60001-UP-UP

3шт.

7

1239 211 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

8шт.

8

1239 962 H2

GASKET - REAR COVER

SN: A60001-UP-UP

1шт.

9

1240 092 H1

SPACER - STARTING MOTOR

SN: A60001-UP-UP

1шт.

10

1239 975 H1

DOWEL, PIN

SN: A60001-UP-UP

2шт.

11

1266 424 H1

BOLT

SN: A60001-UP-UP

9шт.

12

1295 251 H1

HOUSING, FLYWHEEL

SN: A60001-UP-UP

1шт.
