Запчасти Komatsu WA500-1LC FIG. A-A ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

1295 923 H91

HEAD ASSEMBLY, CYLINDER

SN: A60001-UP-UP

3шт.

1

1238 239 H1

COLLET, VALVE

SN: A60001-UP-UP

16шт.

2

1238 270 H2

VALVE, INTAKE

SN: A60001-UP-UP

4шт.

3

1252 824 H2

VALVE, EXHAUST

SN: A60001-UP-UP

4шт.

4

1238 410 H1

GUIDE, VALVE SPRING

SN: A60001-UP-UP

8шт.

5

1238 852 H1

SPRING, VALVE

SN: A60001-UP-UP

8шт.

6

NSS

HEAD, CYLINDER

SN: A60001-UP-UP

1шт.

7

1238 226 H1

GUIDE - VALVE CROSSHEAD

SN: A60001-UP-UP

4шт.

8

1238 336 H2

PLUG, EXPANSION

SN: A60001-UP-UP

3шт.

9

1246 113 H1

PLUG, EXPANSION

SN: A60001-UP-UP

8шт.

10

1239 149 H1

O-RING

SN: A60001-UP-UP

2шт.

11

1241 724 H1

SLEEVE, INJECTOR

SN: A60001-UP-UP

2шт.

12

1266 585 H1

GUIDE - VALVE STEM

SN: A60001-UP-UP

8шт.

13

1295 925 H1

GUIDE - VALVE SPRING

SN: A60001-UP-UP

8шт.

14

1238 566 H1

INSERT, VALVE

SN: A60001-UP-UP

4шт.

15

1239 382 H1

INSERT, VALVE

SN: A60001-UP-UP

4шт.

16

1238 124 H1

PLUG, PIPE

SN: A60001-UP-UP

10шт.

17

1240 019 H1

PIN, GROOVE

SN: A60001-UP-UP

6шт.

18

1295 488 H1

BOLT

SN: A60001-UP-UP

36шт.

19

1253 429 H1

GASKET - CYLINDER HEAD

SN: A60001-UP-UP

3шт.

20

1241 837 H1

WASHER, PLAIN

SN: A60001-UP-UP

36шт.
