Запчасти Komatsu WA500-1LC FIG. K-A СИДЕНЬЕ ОПЕРАТОРА - С ВОЗД. ПОДВЕСКОЙ КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

423-57-A2100

SEAT ASSEMBLY - OPERATOR'S

SN: A60001-UP-UP

1шт.

1

423-57-A2410

UPPER SEAT ASSEMBLY

SN: A60001-UP-UP

1шт.

2

423-57-A2420

KIT, BACK COVER

SN: A60001-UP-UP

1шт.

3

206-57-A1430

KIT, BACK FOAM

SN: A60001-UP-UP

1шт.

4

423-57-A2430

KIT, SEAT COVER

SN: A60001-UP-UP

1шт.

5

206-57-A1450

KIT, SEAT FOAM

SN: A60001-UP-UP

1шт.

6

206-57-A1460

KIT, FRAME

SN: A60001-UP-UP

1шт.

7

206-57-A1470

KIT, CABLE ADJUSTMENT

SN: A60001-UP-UP

1шт.

8

206-57-A1480

KIT, SPRING - HEIGHT RISER

SN: A60001-UP-UP

1шт.

9

206-57-A1490

KIT, LATCH - HEIGHT RISER

SN: A60001-UP-UP

1шт.

10

206-57-A1510

KIT, DAMPER ASSEMBLY

SN: A60001-UP-UP

1шт.

11

206-57-A1520

SUSPENSION ASSEMBLY

SN: A60001-UP-UP

1шт.

12

206-57-A1530

KIT, FORWARD AND BACKWARD ADJUSTMENT

SN: A60001-UP-UP

1шт.

13

206-57-A1540

KIT, WEIGHT ADJUSTER

SN: A60001-UP-UP

1шт.

14

206-57-A1550

KIT, UPSTOP/BUMPSTOP

SN: A60001-UP-UP

1шт.

15

206-57-A1560

KIT, HANDLE - YELLOW

SN: A60001-UP-UP

1шт.

16

206-57-A1570

KIT, HEIGHT RISER

SN: A60001-UP-UP

1шт.

17

206-57-A1580

KIT, SUSPENSION COVER

SN: A60001-UP-UP

1шт.

18

206-57-A1590

SLIDERAIL HANDLE

SN: A60001-UP-UP

1шт.

19

206-57-A1610

KIT, BEARING

SN: A60001-UP-UP

1шт.

|$20

RISER - SEAT TO FLOOR MOUNTING(SEE FIG. K0111-01A0)

SN: A60001-UP-UP

2шт.

|$21

-1шт.

|$22

F1 - ALL KITS CONTAIN REQUIRED MOUNTING HARDWARE.

-1шт.

|$23

-1шт.
