Запчасти Komatsu WA500-1LC FIG. A-A МАСЛЯНЫЙ ПОДДОН ДВИГАТЕЛЬ

1

1238 374 H1

GASKET - OIL CONNECTION

SN: A60001-UP-UP

1шт.

2

1239 212 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

3

1295 912 H1

O-RING

SN: A60001-UP-UP

1шт.

4

1295 913 H1

TUBE - LUBE OIL TRANSFER

SN: A60001-UP-UP

1шт.

5

1295 914 H1

PLATE - CLAMPING

SN: A60001-UP-UP

1шт.

6

1295 915 H1

RETAINER - SEAL

SN: A60001-UP-UP

1шт.

7

1295 916 H1

SEAL - RECTANGULAR RING

SN: A60001-UP-UP

1шт.

8

1241 337 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

2шт.

9

1295 908 H1

WASHER, PLAIN

SN: A60001-UP-UP

2шт.

10

1240 006 H1

WASHER, PLAIN

SN: A60001-UP-UP

1шт.

11

1295 909 H1

NUT - HEX

SN: A60001-UP-UP

2шт.

12

1239 159 H1

PLUG - PIPE

SN: A60001-UP-UP

2шт.

13

1239 161 H1

PLUG - PIPE

SN: A60001-UP-UP

1шт.

14

1295 910 H1

CLIP

SN: A60001-UP-UP

2шт.

15

1295 911 H1

PAN, OIL

SN: A60001-UP-UP

1шт.

16

1295 902 H1

TUBE - LUBE OIL SUCTION

SN: A60001-UP-UP

1шт.

17

1246 402 H1

PLUG - THREADED

SN: A60001-UP-UP

1шт.

18

1295 903 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

28шт.

19

1295 904 H1

GASKET - OIL PAN

SN: A60001-UP-UP

1шт.

20

1295 905 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

4шт.

21

1295 906 H1

SEAL - DUST

SN: A60001-UP-UP

1шт.

22

1294 074 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

4шт.
