Запчасти Komatsu WA500-1LC FIG. A-A ПЕРЕДН. ПРИВОД COVER ДВИГАТЕЛЬ

|$0

1295 853 H91

COVER, GEAR - FRONT

SN: A60001-UP-UP

1шт.

1

1295 854 H1

COVER, GEAR

SN: A60001-UP-UP

1шт.

2

118 406

BUSHING

SN: A60001-UP-UP

1шт.

3

1295 850 H1

SEAL, OIL

SN: A60001-UP-UP

1шт.

4

1239 448 H1

SEAL, OIL

SN: A60001-UP-UP

1шт.

5

1239 975 H1

DOWEL, PIN

SN: A60001-UP-UP

1шт.

6

1239 989 H1

SHIM

SN: A60001-UP-UP

1шт.

|$7

1239 990 H1

SHIM

SN: A60001-UP-UP

1шт.

|$8

1239 991 H1

SHIM

SN: A60001-UP-UP

1шт.

|$9

1238 496 H1

SHIM

SN: A60001-UP-UP

1шт.

7

1240 054 H1

DOWEL

SN: A60001-UP-UP

1шт.

8

1238 906 H1

O-RING

SN: A60001-UP-UP

1шт.

9

1239 251 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

1шт.

10

1239 252 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

3шт.

11

1239 250 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

9шт.

12

1239 253 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

3шт.

13

1295 851 H1

GASKET - GEAR COVER

SN: A60001-UP-UP

1шт.

14

1238 891 H2

SUPPORT - FRONT ENGINE

SN: A60001-UP-UP

1шт.

15

1267 795 H1

BOLT

SN: A60001-UP-UP

2шт.

16

1295 852 H1

BOLT

SN: A60001-UP-UP

6шт.

17

1238 409 H1

BRACKET - LIFTING

SN: A60001-UP-UP

1шт.

18

1295 849 H1

BRACKET - LIFTING

SN: A60001-UP-UP

1шт.

19

1238 064 H1

BOLT

SN: A60001-UP-UP

2шт.

N/I

1295 848 H1

BOLT

SN: A60001-UP-UP

2шт.

N/I

NSS

SEAL - DUST

SN: A60001-UP-UP

1шт.
