Запчасти Komatsu WA500-1LC FIG. H-A ГИДРОЛИНИЯ - УПРАВЛЯЮЩ. КЛАПАН - E.C.S.S. КЛАПАН И АККУМУЛЯТОРS ГИДРАВЛИКА

1

VALVE, TWO-SPOOL CONTROL(SEE FIG. H0123-01A0)

SN: A60001-UP-UP

1шт.

|$2

OR

-1шт.

1

VALVE, THREE-SPOOL CONTROL(SEE FIG. H0124-01A0)

SN: A60001-UP-UP

1шт.

2

421-62-13740

ADAPTER

SN: A60001-UP-UP

2шт.

|$6

01252-41225

BOLT - ADAPTER MOUNTING

SN: A60001-UP-UP

8шт.

3

07000-13048

O-RING

SN: A60001-UP-UP

2шт.

4

07000-13045

O-RING

SN: A60001-UP-UP

2шт.

5

TUBE (SEE FIG. H4200-05A0)

SN: A60001-UP-UP

1шт.

|$10

01010-81275

BOLT - TUBE MOUNTING

SN: A60001-UP-UP

4шт.

|$11

01643-51032

WASHER

SN: A60001-UP-UP

4шт.

6

425-S99-1170

TUBE - BOOM CYLINDER HEAD END

SN: A60001-UP-UP

1шт.

|$14

OR

-1шт.

6

TUBE - BOOM CYLINDER HEAD END(SEE FIG. H4200-05A0)

SN: A60001-UP-UP

1шт.

|$17

01010-81275

BOLT - TUBE MOUNTING

SN: A60001-UP-UP

4шт.

|$18

01643-51032

WASHER

SN: A60001-UP-UP

4шт.

7

425-S99-1160

TUBE - BOOM CYLINDER ROD END

SN: A60001-UP-UP

1шт.

|$21

OR

-1шт.

7

TUBE - BOOM CYLINDER ROD END(SEE FIG. H4200-05A0)

SN: A60001-UP-UP

1шт.

8

TUBE (SEE FIG. H4200-05A0)

SN: A60001-UP-UP

1шт.

9

07000-13038

O-RING

SN: A60001-UP-UP

2шт.

10

07371-31255

FLANGE

SN: A60001-UP-UP

4шт.

|$27

07372-21035

BOLT - FLANGE

SN: A60001-UP-UP

8шт.

|$28

01643-51032

WASHER

SN: A60001-UP-UP

8шт.

11

BRACKET (SEE FIG. H4200-05A0)

SN: A60001-UP-UP

1шт.

12

07283-33450

U-BOLT - TUBE CLAMPING

SN: A60001-UP-UP

4шт.

|$31

426-09-11160

NUT

SN: A60001-UP-UP

8шт.

|$32

01643-31032

WASHER

SN: A60001-UP-UP

8шт.

13

07002-12434

O-RING

SN: A60001-UP-UP

9шт.

14

07230-10522

NIPPLE

SN: A60001-UP-UP

4шт.

15

425-S99-1220

HOSE - VALVE TO LIFT CYLINDER TUBE

SN: A60001-UP-UP

1шт.

16

07236-50522

ELBOW

SN: A60001-UP-UP

2шт.

N/I

07042-30108

PLUG

SN: A60001-UP-UP

2шт.

17

07235-50522

ELBOW

SN: A60001-UP-UP

3шт.

N/I

07236-50522

ELBOW

SN: A60001-UP-UP

3шт.

18

423-S99-2210

HOSE - VALVE TO LIFT CYLINDER TUBE

SN: A60001-UP-UP

1шт.

19

421-S99-1131

VALVE - E.C.S.S.

SN: A60001-UP-UP

1шт.

|$42

01011-51225

BOLT - VALVE TO BRACKET MOUNTING

SN: A60001-UP-UP

2шт.

|$43

01643-31232

WASHER

SN: A60001-UP-UP

2шт.

20

425-S99-1390

BRACKET - VALVE MOUNTING

SN: A60001-UP-UP

1шт.

|$45

01435-01225

BOLT - BRACKET MOUNTING

SN: A60001-UP-UP

2шт.

21

07123-00508

HOSE - VALVE TO LOW ACCUMULATOR

SN: A60001-UP-UP

1шт.

22

ACCUMULATOR ASSEMBLY - LOW-PRESSURE(SEE FIG. H4201-01A0)

SN: A60001-UP-UP

1шт.

|$48

01010-81230

BOLT - ACCUMULATOR MOUNTING

SN: A60001-UP-UP

2шт.

|$49

01643-31232

WASHER

SN: A60001-UP-UP

2шт.

23

421-S99-1351

U-BOLT - ACCUMULATOR MOUNTING

SN: A60001-UP-UP

1шт.

|$51

01643-31232

WASHER

SN: A60001-UP-UP

2шт.

|$52

426-43-19150

NUT

SN: A60001-UP-UP

2шт.

24

07123-00510

HOSE - VALVE TO HIGH ACCUMULATOR

SN: A60001-UP-UP

1шт.

25

ACCUMULATOR ASSEMBLY - HIGH-PRESSURE (SEE FIG. H4201-02A0)

SN: A60001-UP-UP

1шт.

|$55

01010-81230

BOLT - ACCUMULATOR MOUNTING

SN: A60001-UP-UP

2шт.

|$56

01643-31232

WASHER

SN: A60001-UP-UP

2шт.

26

421-S99-1351

U-BOLT - ACCUMULATOR MOUNTING

SN: A60001-UP-UP

1шт.

|$58

01643-31232

WASHER

SN: A60001-UP-UP

2шт.

|$59

426-43-19150

NUT

SN: A60001-UP-UP

2шт.

27

425-S99-1110

BRACKET - ACCUMULATOR MOUNTING

SN: A60001-UP-UP

2шт.

|$61

01010-81270

BOLT - ACCUMULATOR MOUNTING BRACKET

SN: A60001-UP-UP

8шт.

|$62

01643-31232

WASHER

SN: A60001-UP-UP

16шт.

|$63

01580-11210

NUT

SN: A60001-UP-UP

8шт.

28

04434-53411

CLAMP - HOSE

SN: A60001-UP-UP

3шт.

|$65

07095-20523

CUSHION - HOSE CLAMP

SN: A60001-UP-UP

3шт.

|$66

01435-01016

BOLT - HOSE CLAMP MOUNTING

SN: A60001-UP-UP

3шт.

29

HOSE - VALVE TO RETURN TUBE(SEE FIG. H4200-07A0)

SN: A60001-UP-UP

1шт.

|$68

-1шт.

|$69

F1 - FOR MACHINES WITH E.C.S.S.

-1шт.

|$71

-1шт.

|$72

F2 - FOR MACHINES WITHOUT E.C.S.S.

-1шт.

|$73

-1шт.
