Запчасти Komatsu WA500-1LC FIG. H-A РУЛЕВ. УПРАВЛЕНИЕ И P.O.C. НАСОС ГИДРАВЛИКА

|$0

705-52-30260

PUMP ASSEMBLY, STEERING - SAR80+14

SN: A60001-UP-UP

1шт.

|$1

705-34-38240

PUMP, STEERING - SAR80

SN: A60001-UP-UP

1шт.

1

705-17-03021

BRACKET

SN: A60001-UP-UP

1шт.

|$3

705-17-03352

BUSHING

SN: A60001-UP-UP

2шт.

2

705-17-38010

CASE, GEAR

SN: A60001-UP-UP

1шт.

3

705-17-03220

COVER

SN: A60001-UP-UP

1шт.

|$6

705-17-03352

BUSHING

SN: A60001-UP-UP

2шт.

4

705-19-38430

GEAR, DRIVE

SN: A60001-UP-UP

1шт.

5

705-17-38511

GEAR, DRIVEN

SN: A60001-UP-UP

1шт.

6

705-17-03610

PLATE, SIDE

SN: A60001-UP-UP

2шт.

7

705-17-03473

SEAL, OIL

SN: A60001-UP-UP

2шт.

8

705-17-03443

RING, BACK-UP

SN: A60001-UP-UP

2шт.

9

705-17-03381

O-RING

SN: A60001-UP-UP

2шт.

10

04020-01228

PIN, DOWEL

SN: A60001-UP-UP

4шт.

11

705-17-03760

BOLT

SN: A60001-UP-UP

4шт.

12

01643-51645

WASHER

SN: A60001-UP-UP

4шт.

13

705-17-03870

PLATE

SN: A60001-UP-UP

1шт.

14

705-17-03811

SEAL, OIL

SN: A60001-UP-UP

1шт.

15

04065-05220

RING, RETAINING

SN: A60001-UP-UP

1шт.

|$19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED ONLY TO DESIGNATED DEALERS THAT ARE APPROVED TO PERFORM HYDRAULIC COMPONENT REBUILD.

-1шт.

|$21

-1шт.
