Запчасти Komatsu WA500-1LC FIG. H-A THREE-СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН - СЕКЦ. ASSEMBLIES ГИДРАВЛИКА

|$0

709-13-11901

VALVE ASSEMBLY, THREE-SPOOL

SN: A60001-UP-UP

1шт.

1

NSS

BODY, VALVE

SN: A60001-UP-UP

1шт.

2

700-94-11260

PLUG

SN: A60001-UP-UP

1шт.

3

07000-12018

O-RING

SN: A60001-UP-UP

1шт.

4

07001-02018

RING, BACK-UP

SN: A60001-UP-UP

1шт.

5

07002-03634

O-RING

SN: A60001-UP-UP

1шт.

6

700-22-11370

PLUG

SN: A60001-UP-UP

1шт.

7

07002-02434

O-RING

SN: A60001-UP-UP

1шт.

8

NSS

SPOOL

SN: A60001-UP-UP

2шт.

9

NSS

SPOOL

SN: A60001-UP-UP

1шт.

10

709-12-12241

PLUG

SN: A60001-UP-UP

8шт.

N/I

709-12-12820

PLUG - PORT PB-3

SN: A60001-UP-UP

1шт.

11

709-12-12340

RETAINER

SN: A60001-UP-UP

6шт.

12

709-12-12530

SPRING

SN: A60001-UP-UP

2шт.

13

709-12-12850

SPRING

SN: A60001-UP-UP

1шт.

14

709-12-11721

SPRING

SN: A60001-UP-UP

3шт.

15

709-12-11260

RETAINER

SN: A60001-UP-UP

2шт.

16

709-12-11820

RETAINER

SN: A60001-UP-UP

1шт.

17

709-12-11711

SPRING

SN: A60001-UP-UP

3шт.

18

709-12-12320

CASE

SN: A60001-UP-UP

2шт.

19

709-13-11310

CASE

SN: A60001-UP-UP

1шт.

20

709-12-11310

CASE

SN: A60001-UP-UP

3шт.

21

07000-02065

O-RING

SN: A60001-UP-UP

6шт.

22

709-12-12290

SLEEVE

SN: A60001-UP-UP

5шт.

N/I

709-12-12830

SLEEVE - PORT PB-3

SN: A60001-UP-UP

1шт.

23

709-12-12230

PISTON

SN: A60001-UP-UP

6шт.

24

709-12-11730

SPRING

SN: A60001-UP-UP

5шт.

N/I

709-12-12840

SPRING - PORT PA-3

SN: A60001-UP-UP

1шт.

25

709-12-11810

SPACER

SN: A60001-UP-UP

6шт.

26

07000-02065

O-RING

SN: A60001-UP-UP

6шт.

27

01011-51020

BOLT

SN: A60001-UP-UP

12шт.

28

01602-21030

WASHER, SPRING

SN: A60001-UP-UP

12шт.

29

709-12-11511

VALVE

SN: A60001-UP-UP

1шт.

30

709-12-11520

SEAL

SN: A60001-UP-UP

1шт.

31

709-12-11530

SPRING

SN: A60001-UP-UP

1шт.

32

709-12-11570

FLANGE

SN: A60001-UP-UP

1шт.

33

07000-13048

O-RING

SN: A60001-UP-UP

1шт.

34

01010-61460

BOLT

SN: A60001-UP-UP

2шт.

35

01643-31445

WASHER

SN: A60001-UP-UP

2шт.

36

709-12-11611

PLATE

SN: A60001-UP-UP

1шт.

37

07000-02060

O-RING

SN: A60001-UP-UP

1шт.

38

01010-81425

BOLT

SN: A60001-UP-UP

2шт.

39

709-12-11411

VALVE, CHECK

SN: A60001-UP-UP

3шт.

40

709-12-11430

SPRING

SN: A60001-UP-UP

3шт.

41

709-12-11440

PLATE

SN: A60001-UP-UP

3шт.

42

07000-13048

O-RING

SN: A60001-UP-UP

3шт.

43

01010-31235

BOLT

SN: A60001-UP-UP

12шт.

44

VALVE ASSEMBLY - RELIEF (SEE FIG. H0124-02A0)

SN: A60001-UP-UP

1шт.

45

VALVE ASSEMBLY - SUCTION AND SAFETY (SEE FIG. H0124-02A0)

SN: A60001-UP-UP

4шт.

46

VALVE ASSEMBLY - SUCTION (SEE FIG. H0124-02A0)

SN: A60001-UP-UP

1шт.

47

VALVE ASSEMBLY - FLOAT SELECTOR (SEE FIG. H0124-02A0)

SN: A60001-UP-UP

1шт.

48

700-11-31980

PLATE, NAME

SN: A60001-UP-UP

1шт.

|$52

-1шт.

|$53

F1 - USED WITH SPOOL IN VALVE BORE DIRECTION D (AT RELIEF VALVE SIDE OF VALVE BODY).

-1шт.

|$55

-1шт.

|$56

F2 - USED WITH SPOOL IN VALVE BORE DIRECTION

-1шт.

|$57

-1шт.
