Запчасти Komatsu WA500-1LC FIG. H-A TWO-СЕКЦ. УПРАВЛЯЮЩ. КЛАПАН - СЕКЦ. ASSEMBLIES ГИДРАВЛИКА

|$0

709-12-11902

VALVE ASSEMBLY, TWO-SPOOL

SN: A60001-UP-UP

1шт.

1

NSS

BODY

SN: A60001-UP-UP

1шт.

2

700-94-11260

PLUG

SN: A60001-UP-UP

1шт.

3

07000-12018

O-RING

SN: A60001-UP-UP

1шт.

4

07001-02018

RING, BACK-UP

SN: A60001-UP-UP

1шт.

5

07002-03634

O-RING

SN: A60001-UP-UP

1шт.

6

700-22-11370

PLUG

SN: A60001-UP-UP

1шт.

7

07002-02434

O-RING

SN: A60001-UP-UP

1шт.

8

NSS

SPOOL

SN: A60001-UP-UP

1шт.

9

NSS

SPOOL

SN: A60001-UP-UP

1шт.

10

709-12-12241

PLUG

SN: A60001-UP-UP

3шт.

11

709-12-12820

PLUG

SN: A60001-UP-UP

1шт.

12

709-12-11211

RETAINER

SN: A60001-UP-UP

4шт.

13

709-12-11820

RETAINER

SN: A60001-UP-UP

1шт.

14

709-12-11260

RETAINER

SN: A60001-UP-UP

1шт.

15

709-12-12530

SPRING

SN: A60001-UP-UP

1шт.

16

709-12-12850

SPRING

SN: A60001-UP-UP

1шт.

17

709-12-11721

SPRING

SN: A60001-UP-UP

2шт.

18

709-12-11711

SPRING

SN: A60001-UP-UP

2шт.

19

709-12-12230

PISTON

SN: A60001-UP-UP

4шт.

20

709-12-11810

SPACER

SN: A60001-UP-UP

4шт.

21

709-12-11730

SPRING

SN: A60001-UP-UP

3шт.

22

709-12-12840

SPRING

SN: A60001-UP-UP

1шт.

23

709-12-11320

CASE

SN: A60001-UP-UP

2шт.

24

709-12-11310

CASE

SN: A60001-UP-UP

2шт.

25

709-12-12290

SLEEVE

SN: A60001-UP-UP

3шт.

26

709-12-12830

SLEEVE

SN: A60001-UP-UP

1шт.

27

07000-02065

O-RING

SN: A60001-UP-UP

8шт.

28

01011-51020

BOLT

SN: A60001-UP-UP

8шт.

29

01602-21030

WASHER, SPRING

SN: A60001-UP-UP

8шт.

30

709-12-11511

VALVE

SN: A60001-UP-UP

1шт.

31

709-12-11520

SEAL

SN: A60001-UP-UP

1шт.

32

709-12-11530

SPRING

SN: A60001-UP-UP

1шт.

33

709-12-11570

FLANGE

SN: A60001-UP-UP

1шт.

34

07000-13048

O-RING

SN: A60001-UP-UP

1шт.

35

01010-61460

BOLT

SN: A60001-UP-UP

2шт.

36

01643-31445

WASHER

SN: A60001-UP-UP

2шт.

37

709-12-11611

PLATE

SN: A60001-UP-UP

1шт.

38

07000-02060

O-RING

SN: A60001-UP-UP

1шт.

39

01010-81425

BOLT

SN: A60001-UP-UP

2шт.

40

709-12-11411

VALVE - CHECK

SN: A60001-UP-UP

2шт.

41

709-12-11430

SPRING

SN: A60001-UP-UP

2шт.

42

709-12-11440

PLATE

SN: A60001-UP-UP

2шт.

43

07000-13048

O-RING

SN: A60001-UP-UP

2шт.

44

01010-81235

BOLT

SN: A60001-UP-UP

8шт.

45

VALVE ASSEMBLY, RELIEF (SEE FIG. H0123-02A0)

SN: A60001-UP-UP

1шт.

46

VALVE ASSEMBLY, SUCTION AND SAFETY (SEE FIG. H0123-02A0)

SN: A60001-UP-UP

2шт.

47

VALVE ASSEMBLY, SUCTION (SEE FIG. H0123-02A0)

SN: A60001-UP-UP

1шт.

48

VALVE ASSEMBLY, FLOAT SELECTOR (SEE FIG. H0123-02A0)

SN: A60001-UP-UP

1шт.

|$49

-1шт.

|$51

-1шт.
