Запчасти Komatsu WA500-1LC FIG. A-A LUBE МАСЛ. НАСОС ДВИГАТЕЛЬ
№
Артикул
Название
Примечание
Количество
1
1295 895 H1
TUBE - PRESSURE SENSING
SN: A60001-UP-UP
1шт.
2
1239 796 H1
ELBOW - PLAIN ADAPTER
SN: A60001-UP-UP
2шт.
3
1239 675 H1
BOLT - WITH WASHER
SN: A60001-UP-UP
2шт.
4
1296 978 H1
BOLT
SN: A60001-UP-UP
2шт.
5
1239 619 H2
GASKET - LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
|$5
1267 784 H92
ASSEMBLY, LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
6
1238 322 H1
O-RING
SN: A60001-UP-UP
2шт.
7
1238 335 H1
WASHER, PLAIN
SN: A60001-UP-UP
1шт.
8
1238 635 H1
PLATE, COVER
SN: A60001-UP-UP
1шт.
9
1239 195 H1
SPRING, PRESSURE
SN: A60001-UP-UP
1шт.
10
1239 212 H1
BOLT
SN: A60001-UP-UP
2шт.
11
1239 286 H1
PLUG - RETAINER
SN: A60001-UP-UP
1шт.
12
1239 322 H1
GASKET - PUMP COVER
SN: A60001-UP-UP
1шт.
13
1239 324 H92
COVER, LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
14
1240 036 H1
BUSHING
SN: A60001-UP-UP
3шт.
15
1239 325 H91
GEAR - LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
16
1240 015 H1
BUSHING
SN: A60001-UP-UP
2шт.
17
1239 481 H1
BOLT - WITH WASHER
SN: A60001-UP-UP
1шт.
18
1239 482 H1
BOLT - WITH WASHER
SN: A60001-UP-UP
7шт.
19
1295 086 H1
GASKET - HYDRAULIC PUMP
SN: A60001-UP-UP
1шт.
|$20
1267 797 H91
PUMP - LUBE OIL
SN: A60001-UP-UP
1шт.
20
1238 448 H1
PLUG - RETAINER
SN: A60001-UP-UP
1шт.
21
1238 487 H1
KEY - PLAIN WOODRUFF
SN: A60001-UP-UP
1шт.
22
1238 649 H1
GEAR - LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
23
1239 279 H1
SHAFT - IDLER
SN: A60001-UP-UP
1шт.
24
1239 280 H1
SHAFT - LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
25
1239 318 H1
WASHER, PLAIN
SN: A60001-UP-UP
1шт.
26
1239 319 H1
DISC, VALVE
SN: A60001-UP-UP
1шт.
27
1239 320 H1
SPRING - BYPASS VALVE
SN: A60001-UP-UP
1шт.
28
1239 323 H2
GEAR - LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
29
1267 842 H1
BODY - LUBE OIL PUMP
SN: A60001-UP-UP
1шт.
30
1295 893 H1
PLUNGER - PRESSURE
SN: A60001-UP-UP
1шт.
31
1246 118 H91
PLUG - THREADED
SN: A60001-UP-UP
1шт.
|$33
1246 119 H1
O-RING
SN: A60001-UP-UP
1шт.
Выбрано товаров: 34
