Запчасти Komatsu WA500-1LC FIG. F7-A ГИДРОЛИНИЯ ТРАНСМИССИИ - ГИДРОТРАНСФОРМАТОР - МАСЛООХЛАДИТЕЛЬ И ТРАНСМИССИЯ СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

07000-23035

O-RING - TORQUE CONVERTER

SN: A60001-UP-UP

1шт.

2

425-16-11410

TUBE - TORQUE CONVERTER

SN: A60001-UP-UP

1шт.

|$2

01435-01090

BOLT - TUBE MOUNTING

SN: A60001-UP-UP

2шт.

3

07102-21023

HOSE - TORQUE CONVERTER TO COOLERLOWER INLET PORT

SN: A60001-UP-UP

1шт.

4

425-16-11730

TUBE - LOWER OIL COOLER INLET PORT

SN: A60001-UP-UP

1шт.

5

425-16-11781

BRACKET - LOWER OIL COOLER INLET PORT

SN: A60001-UP-UP

1шт.

|$6

01010-81070

BOLT - BRACKET AND OIL INLET TUBEMOUNTING

SN: A60001-UP-UP

2шт.

|$7

01643-31032

WASHER - M10

SN: A60001-UP-UP

2шт.

6

07000-23035

O-RING - LOWER OIL COOLER INLET PORT

SN: A60001-UP-UP

1шт.

7

07000-13035

O-RING - LOWER OIL COOLER OUTLET PORT

SN: A60001-UP-UP

1шт.

8

425-16-11531

TUBE - LOWER OIL COOLER OUTLET PORT

SN: A60001-UP-UP

1шт.

|$11

01435-01030

BOLT - LOWER OIL COOLER OUTLET TUBEMOUNTING

SN: A60001-UP-UP

2шт.

9

07283-33450

U-BOLT, CLAMP - OIL OUTLET TUBE

SN: A60001-UP-UP

1шт.

|$13

01643-31032

WASHER - M10

SN: A60001-UP-UP

2шт.

|$14

426-09-11160

NUT

SN: A60001-UP-UP

2шт.

10

425-16-11551

BRACKET - LOWER OIL COOLER OUTLETPORT TUBE

SN: A60001-UP-UP

1шт.

|$16

01435-01020

BOLT - BRACKET MOUNTING

SN: A60001-UP-UP

2шт.

11

07102-21003

HOSE - LOWER COOLER TO UPPER COOLERINLET PORT

SN: A60001-UP-UP

1шт.

12

425-16-11521

TUBE - UPPER OIL COOLER INLET PORT

SN: A60001-UP-UP

1шт.

|$19

01435-01060

BOLT - UPPER COOLER INLET TUBEMOUNTING

SN: A60001-UP-UP

2шт.

13

07000-13035

O-RING - UPPER COOLER INLET ANDOUTLET PORTS

SN: A60001-UP-UP

2шт.

14

425-16-11513

TUBE - UPPER COOLER OUTLET PORT TOTRANSMISSION

SN: A60001-UP-UP

1шт.

|$22

01435-01060

BOLT - UPPER COOLER OUTLET TUBE

SN: A60001-UP-UP

2шт.

15

07283-33450

U-BOLT, CLAMP - UPPER COOLER OUTLETTUBE

SN: A60001-UP-UP

1шт.

|$24

01643-31032

WASHER - M10

SN: A60001-UP-UP

2шт.

|$25

426-09-11160

NUT

SN: A60001-UP-UP

2шт.

16

07102-21031

HOSE - UPPER COOLER OUTLET PORT TOTRANSMISSION

SN: A60001-UP-UP

1шт.

17

425-16-11451

TUBE - TRANSMISSION

SN: A60001-UP-UP

1шт.

|$28

01435-01265

BOLT - TRANSMISSION TUBE MOUNTING

SN: A60001-UP-UP

2шт.

18

07000-13035

O-RING - TRANSMISSION

SN: A60001-UP-UP

1шт.

19

421-16-11660

CLIP - TORQUE CONVERTER ANDTRANSMISSION LINES

SN: A60001-UP-UP

12шт.

N/I

01435-01016

BOLT - CLIP MOUNTING

SN: A60001-UP-UP

2шт.

N/I

01435-01025

BOLT - CLIP MOUNTING

SN: A60001-UP-UP

4шт.
