Запчасти Komatsu WA500-1LC FIG. F-A ТРАНСМИССИЯ - ПЕРВ. МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION ASSEMBLY(SEE FIG. F4320-01A0)

SN: A60001-UP-UP

1шт.

1

425-15-12340

CARRIER

SN: A60001-UP-UP

1шт.

2

07018-11355

RING, SEAL

SN: A60001-UP-UP

2шт.

3

425-15-12860

BUSHING

SN: A60001-UP-UP

1шт.

4

425-15-12430

GEAR

SN: A60001-UP-UP

4шт.

5

425-15-19420

BEARING

SN: A60001-UP-UP

4шт.

6

425-15-19440

WASHER, THRUST

SN: A60001-UP-UP

8шт.

|$7

425-15-00110

SHAFT ASSEMBLY

SN: A60001-UP-UP

4шт.

7

NSS

SHAFT

SN: A60001-UP-UP

1шт.

8

07043-00108

PLUG

SN: A60001-UP-UP

1шт.

9

04025-00620

PIN, SPRING

SN: A60001-UP-UP

4шт.

10

425-15-12610

GEAR, RING - FIRST CLUTCH

SN: A60001-UP-UP

1шт.

11

425-15-11130

HOUSING - FIRST CLUTCH

SN: A60001-UP-UP

1шт.

12

232-15-19230

RING, SEAL - FIRST CLUTCH HOUSING

SN: A60001-UP-UP

1шт.

13

425-15-12750

PISTON - FIRST CLUTCH

SN: A60001-UP-UP

1шт.

14

582-15-19250

RING, SEAL - FIRST CLUTCH PISTON

SN: A60001-UP-UP

1шт.

15

195-15-32710

DISC - FIRST CLUTCH

SN: A60001-UP-UP

3шт.

16

425-15-12740

PLATE - FIRST CLUTCH

SN: A60001-UP-UP

2шт.

17

175-15-42880

SPRING - FIRST CLUTCH DISC

SN: A60001-UP-UP

18шт.

18

234-15-15230

SPRING

SN: A60001-UP-UP

12шт.

19

04020-01434

PIN, DOWEL

SN: A60001-UP-UP

2шт.

20

04020-01434

PIN, DOWEL

SN: A60001-UP-UP

2шт.

|$22

425-15-00130

SHAFT ASSEMBLY - FIRST CLUTCH

SN: A60001-UP-UP

1шт.

21

NSS

SHAFT

SN: A60001-UP-UP

1шт.

22

423-15-12190

PLUG

SN: A60001-UP-UP

1шт.

23

425-15-11550

COLLAR

SN: A60001-UP-UP

1шт.

24

04064-08530

RING, RETAINING

SN: A60001-UP-UP

1шт.

25

PIN - FIRST AND THIRD CLUTCH HOUSINGS (SEE FIG. F4320-05A0)

SN: A60001-UP-UP

6шт.

|$28

KIT, SERVICE - TRANSMISSION(SEE FIG. F4900-01A0)

SN: A60001-UP-UP

1шт.

|$29

-1шт.

|$30

F1 - INCLUDED IN TRANSMISSION SERVICE KIT.

-1шт.

|$31

-1шт.
