Запчасти Komatsu WA500-1LC FIG. F-A ТРАНСМИССИЯ - THIRD МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION ASSEMBLY(SEE FIG. F4320-01A0)

SN: A60001-UP-UP

1шт.

1

425-15-12330

CARRIER

SN: A60001-UP-UP

1шт.

2

425-15-12430

GEAR

SN: A60001-UP-UP

4шт.

3

425-15-19420

BEARING

SN: A60001-UP-UP

4шт.

4

09233-12920

WASHER, THRUST

SN: A60001-UP-UP

8шт.

|$5

425-15-00110

SHAFT ASSEMBLY - THIRD CLUTCH

SN: A60001-UP-UP

4шт.

5

NSS

SHAFT

SN: A60001-UP-UP

1шт.

6

07043-00108

PLUG

SN: A60001-UP-UP

1шт.

7

04025-00620

PIN

SN: A60001-UP-UP

4шт.

8

425-15-12240

GEAR

SN: A60001-UP-UP

1шт.

9

04064-09530

RING, RETAINING

SN: A60001-UP-UP

1шт.

10

425-15-12254

GEAR

SN: A60001-UP-UP

1шт.

11

06000-06919

BEARING

SN: A60001-UP-UP

1шт.

12

04077-00130

RING, RETAINING

SN: A60001-UP-UP

1шт.

13

425-15-12620

GEAR, RING - THIRD CLUTCH

SN: A60001-UP-UP

1шт.

14

04070-00150

RING, RETAINING

SN: A60001-UP-UP

1шт.

15

425-15-11140

HOUSING - THIRD CLUTCH

SN: A60001-UP-UP

1шт.

16

562-15-19230

RING, SEAL - THIRD CLUTCH HOUSING

SN: A60001-UP-UP

1шт.

17

425-15-12760

PISTON - THIRD CLUTCH

SN: A60001-UP-UP

1шт.

18

567-15-12820

RING, SEAL - THIRD CLUTCH PISTON

SN: A60001-UP-UP

1шт.

19

195-15-32710

DISC - THIRD CLUTCH

SN: A60001-UP-UP

3шт.

20

425-15-12740

PLATE - THIRD CLUTCH

SN: A60001-UP-UP

2шт.

21

175-15-42880

SPRING - THIRD CLUTCH DISC

SN: A60001-UP-UP

18шт.

22

234-15-15230

SPRING

SN: A60001-UP-UP

12шт.

23

155-15-12770

PIN - FIRST AND THIRD CLUTCH HOUSINGS

SN: A60001-UP-UP

6шт.

24

04020-01434

PIN, DOWEL

SN: A60001-UP-UP

2шт.

25

SHAFT ASSEMBLY, FIRST CLUTCH (SEE FIG. F4900-01A0)

SN: A60001-UP-UP

1шт.

|$27

-1шт.

|$28

KIT, SERVICE - TRANSMISSION

-1шт.

|$29

-1шт.

|$31

-1шт.

|$32

F1 - INCLUDED IN TRANSMISSION SERVICE KIT.

-1шт.

|$33

-1шт.
