Запчасти Komatsu WA500-1LC FIG. F-A ТРАНСМИССИЯ - РЕВЕРС МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION ASSEMBLY(SEE FIG. F4320-01A0)

SN: A60001-UP-UP

1шт.

1

425-15-12110

SHAFT

SN: A60001-UP-UP

1шт.

2

07018-10653

RING, SEAL

SN: A60001-UP-UP

1шт.

3

07018-10854

RING, SEAL

SN: A60001-UP-UP

2шт.

4

07018-10552

RING, SEAL

SN: A60001-UP-UP

1шт.

|$5

425-15-00100

HOUSING ASSEMBLY

SN: A60001-UP-UP

1шт.

5

NSS

HOUSING

SN: A60001-UP-UP

1шт.

6

07043-00312

PLUG

SN: A60001-UP-UP

2шт.

7

06000-06924

BEARING

SN: A60001-UP-UP

1шт.

8

04077-00165

RING, RETAINING

SN: A60001-UP-UP

1шт.

9

04070-00120

RING, RETAINING

SN: A60001-UP-UP

1шт.

10

425-15-12310

CARRIER

SN: A60001-UP-UP

1шт.

11

07018-11355

RING, SEAL

SN: A60001-UP-UP

2шт.

12

06000-06013

BEARING

SN: A60001-UP-UP

1шт.

13

04077-00100

RING, RETAINING

SN: A60001-UP-UP

1шт.

14

04064-06525

RING, RETAINING

SN: A60001-UP-UP

1шт.

15

425-15-12410

GEAR

SN: A60001-UP-UP

4шт.

16

425-15-19410

BEARING

SN: A60001-UP-UP

4шт.

17

09233-13820

WASHER, THRUST

SN: A60001-UP-UP

8шт.

|$19

425-15-00150

SHAFT ASSEMBLY

SN: A60001-UP-UP

4шт.

18

NSS

SHAFT

SN: A60001-UP-UP

1шт.

19

07043-00108

PLUG

SN: A60001-UP-UP

1шт.

20

04025-00620

PIN, SPRING

SN: A60001-UP-UP

4шт.

21

425-15-11180

HOUSING - REVERSE CLUTCH

SN: A60001-UP-UP

1шт.

22

425-15-19250

SEAL, RING - REVERSE CLUTCH HOUSING

SN: A60001-UP-UP

1шт.

23

425-15-12770

PISTON - REVERSE CLUTCH

SN: A60001-UP-UP

1шт.

24

582-15-19250

SEAL, RING - REVERSE CLUTCH PISTON

SN: A60001-UP-UP

1шт.

25

195-15-32710

DISC - REVERSE CLUTCH

SN: A60001-UP-UP

4шт.

26

425-15-12740

PLATE - REVERSE CLUTCH

SN: A60001-UP-UP

3шт.

27

175-15-42880

SPRING - REVERSE CLUTCH DISC

SN: A60001-UP-UP

24шт.

28

425-15-11270

PIN - FORWARD AND REVERSE HOUSINGS

SN: A60001-UP-UP

6шт.

29

425-15-12920

SPRING

SN: A60001-UP-UP

12шт.

30

425-15-12660

GEAR, RING - REVERSE CLUTCH

SN: A60001-UP-UP

1шт.

31

04020-01434

PIN, DOWEL

SN: A60001-UP-UP

2шт.

32

425-15-11250

BOLT

SN: A60001-UP-UP

15шт.

33

425-15-11260

BOLT

SN: A60001-UP-UP

2шт.

34

145-14-11570

WASHER

SN: A60001-UP-UP

17шт.

35

425-15-12210

GEAR

1шт.

36

06000-06917

BEARING

SN: A60001-UP-UP

1шт.

|$39

KIT, SERVICE - TRANSMISSION(SEE FIG. F4900-01A0)

SN: A60001-UP-UP

1шт.

|$40

-1шт.

|$41

F1 - INCLUDED IN TRANSMISSION SERVICE KIT.

-1шт.

|$42

-1шт.
