Запчасти Komatsu WA500-1LC FIG. F-A ТРАНСМИССИЯ - ПЕРЕД. И FOURTH МУФТА СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

TRANSMISSION ASSEMBLY(SEE FIG. F4320-01A0)

SN: A60001-UP-UP

1шт.

|$1

425-15-00140

CARRIER ASSEMBLY

SN: A60001-UP-UP

1шт.

1

NSS

CARRIER

1шт.

2

145-14-11320

PLUG

SN: A60001-UP-UP

4шт.

3

425-15-12420

GEAR

SN: A60001-UP-UP

8шт.

4

425-15-19410

BEARING

8шт.

5

09233-13820

WASHER, THRUST

SN: A60001-UP-UP

16шт.

|$7

425-15-00120

SHAFT ASSEMBLY

SN: A60001-UP-UP

4шт.

6

NSS

SHAFT

SN: A60001-UP-UP

1шт.

7

07043-00108

PLUG

SN: A60001-UP-UP

1шт.

8

04025-00620

PIN

4шт.

9

425-15-12650

GEAR, RING - FOURTH CLUTCH

SN: A60001-UP-UP

1шт.

10

425-15-19530

RING, RETAINING

SN: A60001-UP-UP

1шт.

11

425-15-12890

COVER

1шт.

12

04025-00620

PIN, SPRING

SN: A60001-UP-UP

1шт.

13

425-15-19540

RING, RETAINING

SN: A60001-UP-UP

1шт.

14

425-15-12640

GEAR, RING - FORWARD CLUTCH

SN: A60001-UP-UP

1шт.

15

425-15-11170

HOUSING - FORWARD CLUTCH

SN: A60001-UP-UP

1шт.

16

562-15-19230

RING, SEAL - FORWARD CLUTCH HOUSING

1шт.

17

425-15-12760

PISTON - FORWARD CLUTCH

SN: A60001-UP-UP

1шт.

18

567-15-12820

RING, SEAL - FORWARD CLUTCH PISTON

SN: A60001-UP-UP

1шт.

19

195-15-32710

DISC - FORWARD CLUTCH

SN: A60001-UP-UP

4шт.

20

425-15-12740

PLATE - FORWARD CLUTCH

3шт.

21

175-15-42880

SPRING - FORWARD CLUTCH DISC

SN: A60001-UP-UP

24шт.

22

425-15-12920

SPRING

SN: A60001-UP-UP

12шт.

23

04020-01434

PIN, DOWEL

SN: A60001-UP-UP

2шт.

24

425-15-12220

GEAR

1шт.

25

425-15-11160

HOUSING - FOURTH CLUTCH

SN: A60001-UP-UP

1шт.

26

232-15-19230

RING, SEAL - FOURTH CLUTCH HOUSING

SN: A60001-UP-UP

1шт.

27

425-15-12750

PISTON - FOURTH CLUTCH

SN: A60001-UP-UP

1шт.

28

582-15-19250

RING, SEAL - FOURTH CLUTCH PISTON

1шт.

29

195-15-32710

DISC - FOURTH CLUTCH

SN: A60001-UP-UP

3шт.

30

425-15-12740

PLATE - FOURTH CLUTCH

SN: A60001-UP-UP

2шт.

31

175-15-42880

SPRING - FOURTH CLUTCH DISC

SN: A60001-UP-UP

18шт.

32

234-15-15230

SPRING

12шт.

33

04020-01434

PIN, DOWEL

SN: A60001-UP-UP

2шт.

34

425-15-12230

GEAR

SN: A60001-UP-UP

1шт.

35

06000-06013

BEARING

1шт.

36

425-15-12850

COLLAR

SN: A60001-UP-UP

1шт.

37

07018-11355

RING, SEAL

SN: A60001-UP-UP

2шт.

38

PIN - FORWARD AND REVERSE HOUSINGS (SEE FIG. F4320-02A0)

6шт.

39

GEAR, RING - SECOND CLUTCH (SEE FIG. F4320-04A0)

SN: A60001-UP-UP

1шт.

|$42

SN: A60001-UP-UP

-1шт.

|$43

KIT, SERVICE - TRANSMISSION(SEE FIG. F4900-01A0)

1шт.

|$44

-1шт.

|$45

F1 - INCLUDED IN TRANSMISSION SERVICE KIT.

-1шт.

|$46

-1шт.
