Запчасти Komatsu WA500-1LC FIG. F-A ГИДРОТРАНСФОРМАТОР СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

711-53-00011

TORQUE CONVERTER ASSEMBLY

SN: A60001-UP-UP

1шт.

1

711-53-13130

HOUSING

SN: A60001-UP-UP

1шт.

2

04530-12030

BOLT, EYE

SN: A60001-UP-UP

2шт.

3

711-53-14212

GEAR

SN: A60001-UP-UP

4шт.

4

711-35-14230

BEARING

SN: A60001-UP-UP

4шт.

5

711-35-14120

PLATE

SN: A60001-UP-UP

4шт.

6

04065-09530

RING

SN: A60001-UP-UP

4шт.

7

01530-04812

NUT

SN: A60001-UP-UP

4шт.

8

711-53-13110

HOUSING

SN: A60001-UP-UP

1шт.

9

07042-20108

PLUG

SN: A60001-UP-UP

1шт.

10

07043-00617

PLUG

SN: A60001-UP-UP

1шт.

11

07000-65460

O-RING - BETWEEN HOUSINGS

SN: A60001-UP-UP

1шт.

12

07000-63035

O-RING - BETWEEN HOUSINGS

SN: A60001-UP-UP

1шт.

13

01010-81235

BOLT - ASSEMBLING HOUSINGS TOGETHER

SN: A60001-UP-UP

11шт.

14

01602-21236

WASHER, LOCK

SN: A60001-UP-UP

11шт.

15

09607-05080

PLATE, NAME

SN: A60001-UP-UP

1шт.

16

04418-03060

SCREW

SN: A60001-UP-UP

4шт.

17

07000-05490

O-RING - TORQUE CONVERTER TOTRANSMISSION

SN: A60001-UP-UP

1шт.

18

07000-73042

O-RING - TORQUE CONVERTER TOTRANSMISSION

SN: A60001-UP-UP

1шт.

19

07000-73038

0-RING - TORQUE CONVERTER TOTRANSMISSION

SN: A60001-UP-UP

1шт.

20

01010-31250

BOLT - TORQUE CONVERTER TOTRANSMISSION MOUNTING

SN: A60001-UP-UP

4шт.

21

01643-31232

WASHER - M12

SN: A60001-UP-UP

4шт.

22

01010-31235

BOLT - TORQUE CONVERTER TOTRANSMISSION MOUNTING

SN: A60001-UP-UP

8шт.

23

01643-31232

WASHER - M12

SN: A60001-UP-UP

8шт.

24

426-01-11310

BRACKET

SN: A60001-UP-UP

2шт.

25

419-43-18190

SPACER

SN: A60001-UP-UP

2шт.

|$26

711-53-05010

KIT, SERVICE - TORQUE CONVERTER

SN: A60001-UP-UP

1шт.

|$27

-1шт.

|$28

F1 - INCLUDED IN TORQUE CONVERTER SERVICE KIT.

-1шт.

|$29

-1шт.
