Запчасти Komatsu WA500-1LC FIG. A-A ТУРБОНАГНЕТАТЕЛЬ ДВИГАТЕЛЬ

|$0

1268 303 H91

TURBOCHARGER KIT

SN: A60001-UP-UP

1шт.

1

1296 594 H1

GASKET - EXHAUST-OUT CONNECTION

SN: A60001-UP-UP

1шт.

2

1238 594 H1

GASKET - CONNECTION

SN: A60001-UP-UP

1шт.

3

1252 716 H1

GASKET - CONNECTION

SN: A60001-UP-UP

1шт.

4

1246 119 H1

SEAL, O-RING

SN: A60001-UP-UP

1шт.

|$5

NSS

TURBOCHARGER

SN: A60001-UP-UP

1шт.

5

1241 715 H1

NUT - REGULAR HEXAGON

SN: A60001-UP-UP

1шт.

6

1268 516 H91

CLAMP - V-BAND

SN: A60001-UP-UP

1шт.

7

1294 497 H1

DATAPLATE

SN: A60001-UP-UP

1шт.

8

1268 517 H1

SHIELD - TURBOCHARGER HEAT

SN: A60001-UP-UP

1шт.

9

1246 471 H1

SCREW, DRIVE

SN: A60001-UP-UP

4шт.

10

1268 518 H1

BEARING - TURBOCHARGER THRUST

SN: A60001-UP-UP

1шт.

11

1268 519 H1

HOUSING, TURBINE

SN: A60001-UP-UP

1шт.

12

1268 520 H1

BAFFLE - OIL

SN: A60001-UP-UP

1шт.

13

1268 522 H1

PLATE, CLAMPING

SN: A60001-UP-UP

1шт.

14

1268 523 H1

DATAPLATE

SN: A60001-UP-UP

1шт.

15

1268 532 H1

SEAL, SPLIT RING

SN: A60001-UP-UP

2шт.

16

1241 395 H1

SEAL, SPLIT RING

SN: A60001-UP-UP

1шт.

17

1268 533 H91

HOUSING - TURBOCHARGER BEARING

SN: A60001-UP-UP

1шт.

|$19

1268 534 H1

HOUSING - TURBOCHARGER BEARING

SN: A60001-UP-UP

1шт.

|$20

1268 535 H1

PIN, STRAIGHT

SN: A60001-UP-UP

2шт.

18

1268 536 H1

BOLT - WITH WASHER

SN: A60001-UP-UP

10шт.

19

1295 931 H1

HOUSING, COMPRESSOR

SN: A60001-UP-UP

1шт.

20

1268 539 H1

RING, RETAINING

SN: A60001-UP-UP

4шт.

21

1268 540 H1

RING, RETAINING

SN: A60001-UP-UP

1шт.

22

1268 541 H1

BEARING - TURBOCHARGER

SN: A60001-UP-UP

2шт.

23

1268 542 H1

RING, RETAINING

SN: A60001-UP-UP

1шт.

24

1268 543 H1

O-RING

SN: A60001-UP-UP

1шт.

25

1268 544 H1

SLEEVE - TURBOCHARGER

SN: A60001-UP-UP

1шт.

26

1268 545 H1

PLATE, OIL CONTROL

SN: A60001-UP-UP

1шт.

27

1268 521 H1

NUT, LOCK

SN: A60001-UP-UP

1шт.

28

1268 524 H1

SLINGER, OIL

SN: A60001-UP-UP

1шт.

29

1268 531 H1

COLLAR, THRUST

SN: A60001-UP-UP

1шт.

30

1268 515 H1

WHEEL - TURBOCHARGER

SN: A60001-UP-UP

1шт.

31

1268 537 H1

IMPELLER - TURBOCHARGER

SN: A60001-UP-UP

1шт.

32

1267 649 H1

NUT - HEX FLANGE

SN: A60001-UP-UP

4шт.

33

1267 648 H1

STUD

SN: A60001-UP-UP

4шт.
