Запчасти Komatsu WA500-1L ГИДРОЛИНИЯ ТРАНСМИССИИ ГИДРОТРАНСФОРМАТОР - МАСЛООХЛАДИТЕЛЬ - ТРАНСМИССИЯ ГИДРОТРАНСФОРМАТОР И ТРАНСМИССИЯ

1

07000-23035

O-RING, AT TORQUE CONVERTER

1шт.

2

425-16-11410

TUBE, AT TORQUE CONVERTER

1шт.

|$2

01435-01090

BOLT, MOUNT TUBE

2шт.

3

07102-21023

HOSE, TORQUE CONVERTER TO LOWER COOLER INLET PORT

1шт.

4

425-16-11730

TUBE, AT LOWER OIL COOLER INLET PORT

1шт.

5

425-16-11781

BRACKET, AT LOWER OIL COOLER INLET PORT

1шт.

|$6

01010-51070

BOLT, MOUNT BRACKET AND OIL INLET TUBE

2шт.

|$7

01643-31032

WASHER

2шт.

6

07000-23035

O-RING, AT LOWER OIL COOLER INLET PORT

1шт.

7

07000-13035

O-RING, AT LOWER OIL COOLER OUTLET PORT

1шт.

8

425-16-11531

TUBE, AT LOWER OIL COOLER OUTLET PORT

1шт.

|$11

01435-01030

BOLT, MOUNT LOWER OIL COOLER OUTLET TUBE

2шт.

9

07283-33450

U-BOLT, CLAMP OIL OUTLET TUBE

1шт.

|$13

01643-31032

WASHER

2шт.

|$14

426-09-11160

NUT

2шт.

10

425-16-11551

BRACKET, AT LOWER OIL COOLER OUTLET PORT

1шт.

|$16

01435-01020

BOLT, MOUNT BRACKET

2шт.

11

07102-21003

HOSE, LOWER COOLER TO UPPER COOLER INLET PORT

1шт.

12

425-16-11521

TUBE, AT UPPER OIL COOLER INLET PORT

1шт.

|$19

01435-01060

BOLT, MOUNT UPPER COOLER INLET TUBE

2шт.

13

07000-13035

O-RING, UPPER COOLER INLET AND OUTLET PORTS

2шт.

14

425-16-11513

TUBE, UPPER COOLER OUTLET PORT TO TRANSMISSION

1шт.

|$22

01435-01060

BOLT, UPPER COOLER OUTLET TUBE

1шт.

15

07283-33450

U-BOLT, CLAMP UPPER COOLER OUTLET TUBE

1шт.

|$24

01643-31032

WASHER

2шт.

|$25

426-09-11160

NUT

2шт.

16

07102-21031

HOSE, UPPER COOLER OUTLET PORT TO TRANSMISSION

1шт.

17

425-16-11451

TUBE, AT TRANSMISSION

1шт.

|$28

01435-01265

BOLT, MOUNT TRANSMISSION TUBE

1шт.

18

07000-13035

O-RING, AT TRANSMISSION

1шт.

19

421-16-11660

CLIP, TORQUE CONVERTER AND TRANSMISSION LINES

12шт.

|$31

01435-01016

BOLT, MOUNT CLIPS

3шт.

|$32

01435-01025

BOLT, MOUNT CLIPS

4шт.
