Запчасти Komatsu WA500-1L КОМПРЕССОР (REFRIGERANT) АКСЕССУАРЫ

|$0

6210-81-3111

COMPRESSOR, AIR (REFRIGERANT)

1шт.

1

DK487000-6500

CASE, CRANK

1шт.

2

DK487653-0300

CRANKSHAFT

1шт.

3

DK035620-6000

BEARING

1шт.

4

DK036202-0700

BEARING

1шт.

5

DK487003-7301

COVER, BEARING

1шт.

6

DK487061-4300

O-RING, BEARING COVER

1шт.

7

DK487061-4500

O-RING, FLANGE

1шт.

8

DK487061-3700

O-RING, CYLINDER

1шт.

9

DK487001-3200

CYLINDER

1шт.

10

DK487013-2100

ROD, CONNECTING

1шт.

11

DK487009-1601

PISTON

1шт.

12

DK487010-3420

RING SET, PISTON

1шт.

13

DK487012-0100

PIN, PISTON

1шт.

14

DK016110-1610

RING, SNAP

2шт.

15

DK487020-2200

GASKET, CYLINDER HEAD

1шт.

|$16

DK487018-5220

CYLINDER HEAD ASSEMBLY

1шт.

|$17

DK487018-5320

HEAD ASSEMBLY, CYLINDER

1шт.

16

DK487018-5300

HEAD, CYLINDER

1шт.

17

DK487061-4000

O-RING, DELIVERY VALVE

1шт.

18

DK487042-1100

GUIDE, SPRING

1шт.

19

DK487061-4100

O-RING, DELIVERY VALVE

1шт.

20

DK487031-2000

SPRING, DELIVERY VALVE

1шт.

21

DK487026-1700

VALVE, DELIVERY

1шт.

22

DK487030-2200

SEAT, DELIVERY VALVE

1шт.

23

DK487024-1300

SPRING, UNLOADER VALVE

1шт.

24

DK487039-0300

GASKET, INTAKE VALVE

1шт.

25

DK487025-1000

SEAT, INTAKE VALVE

1шт.

26

DK487026-1600

VALVE, INTAKE

1шт.

27

DK487027-1200

SPRING, INTAKE VALVE

1шт.

28

DK487028-1700

GUIDE, INTAKE VALVE

1шт.

29

DK487021-2320

VALVE ASSEMBLY, UNLOADER

1шт.

30

DK487073-0900

FLANGE

1шт.

31

DK156603-4400

BOLT, MOUNT BEARING COVER

4шт.

32

DK010110-2570

BOLT, MOUNT CYLINDER

4шт.

33

DK487088-0000

BOLT, MOUNT CYLINDER HEAD

2шт.

34

DK014110-8440

WASHER, LOCK - BEARING COVER

4шт.

35

DK014111-0440

WASHER, LOCK - CYLINDER HEAD

4шт.

36

DK487351-0800

WASHER, LOCK - FLANGE

4шт.

37

DK025805-1610

KEY, WOODRUFF - CRANKSHAFT

1шт.

38

DK014020-8140

WASHER, BEARING COVER

4шт.

39

DK487017-1600

BOLT, MOUNT FLANGE

4шт.

40

DK487088-0100

BOLT, MOUNT CYLINDER HEAD

2шт.

N/I

GASKET KIT, AIR COMPRESSOR (SEE PG E9-002)

-29шт.

|$46

-1шт.

|$45

F1 - INCLUDED IN AIR COMPRESSOR GASKET KIT 6211-K8-0104.

-1шт.

|$47

-1шт.
