Запчасти Komatsu WA500-1 V-ОБРАЗН КОВШ (С ЗУБЬЯМИ) КАТАЛОГИ ЗЧ

|$$1

3.0M3 ROCK BUCKET{(WITH ADAPTER TOOTH)}

-1шт.

|1

425-819-1300

BUCKET ASS'Y,(WITH TOOTH)

SN: 20001-UP

1шт.

1

425-807-1310

BUCKET

SN: 20001-UP

1шт.

2

425-70-12132

PLATE (WELDED)

SN: 20001-UP

2шт.

3

425-809-1121

EDGE (WELDED)

SN: 20001-UP

1шт.

4

425-809-1350

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

5

425-809-1360

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

6

425-809-1340

PLATE (WELDED)

SN: 20001-UP

2шт.

7

425-70-12141

PLATE (WELDED)

SN: 20001-UP

2шт.

|$$10

HEAVY DUTY BUCKET

-1шт.

|$$11

4.0M3 BUCKET{(WITH ADAPTER TOOTH)}

-1шт.

|8

425-V65-1213

BUCKET ASS'Y,(WITH TOOTH)

SN: 20001-UP

1шт.

8

425-V65-1113

BUCKET

SN: 20001-UP

1шт.

9

425-V65-1170

PLATE (WELDED)

SN: 20001-UP

2шт.

10

425-809-1122

EDGE (WELDED)

SN: 20001-UP

1шт.

11

425-V65-1150

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

12

425-V65-1160

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

13

425-V65-1181

PLATE (WELDED)

SN: 20001-UP

2шт.

14

426-70-12470

GUARD (WELDED)

SN: 20001-UP

2шт.

15

425-V65-1141

PLATE (WELDED)

SN: 20001-UP

2шт.
