Запчасти Komatsu WA500-1 V-ОБРАЗН КОВШ КАТАЛОГИ ЗЧ

|$$1

4.0M3 BUCKET

-1шт.

|1

425-809-1410

BUCKET ASS'Y

SN: 20001-UP

1шт.

1

425-809-1310

BUCKET

SN: 20001-UP

1шт.

2

425-70-12132

PLATE (WELDED)

SN: 20001-UP

2шт.

3

425-809-1121

EDGE (WELDED)

SN: 20001-UP

1шт.

4

425-809-1350

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

5

425-809-1360

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

6

425-809-1340

PLATE (WELDED)

SN: 20001-UP

2шт.

7

425-70-12141

PLATE (WELDED)

SN: 20001-UP

2шт.

|$$10

3.0M3 BUCKET

-1шт.

8

425-V70-1111

BUCKET

SN: 20001-UP

1шт.

9

425-V70-1120

PLATE (WELDED)

SN: 20001-UP

2шт.

10

425-809-1121

EDGE (WELDED)

SN: 20001-UP

1шт.

11

425-809-1152

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

12

425-809-1162

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

13

425-V70-1130

PLATE (WELDED)

SN: 20001-UP

2шт.

14

425-V70-1140

PLATE (WELDED)

SN: 20001-UP

2шт.

15

425-70-12141

PLATE (WELDED)

SN: 20001-UP

2шт.

|$$19

3.0M3 ROCK BUCKET

-1шт.

8

425-V70-1111

BUCKET

SN: 20001-UP

1шт.

9

425-V70-1120

PLATE (WELDED)

SN: 20001-UP

2шт.

10

425-809-1121

EDGE (WELDED)

SN: 20001-UP

1шт.

11

425-809-1152

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

12

425-809-1162

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

13

425-V70-1130

PLATE (WELDED)

SN: 20001-UP

2шт.

14

425-V70-1140

PLATE (WELDED)

SN: 20001-UP

2шт.

15

425-70-12141

PLATE (WELDED)

SN: 20001-UP

2шт.
