Запчасти Komatsu WA50-6 МАРКИРОВКА, (№8-) МАРКИРОВКА, ДЛЯ АНГЛ., США И PUERTO RICO, СИСТЕМА ROPS

1

42A-93-51133

Oil Chart

SN: 62776-UP

1шт.

1

42A-93-51132

Oil Chart

SN: 60001-62775

1шт.

2

09652-31221

Plate, Caution, Diesel Fuel

SN: 60001-UP

1шт.

3

42A-93-51110

Plate, Mark, WA50

SN: 60001-UP

1шт.

4

42A-93-51120

Plate, Mark, WA50

SN: 60001-UP

1шт.

5

09601-10002

Plate, Name (Limited Supply)

SN: 60001-UP

1шт.

6

04418-13060

Screw

SN: 60001-UP

4шт.

7

09963-03001

Tag, Danger, Do Not Operate

SN: 60001-UP

1шт.

8

09690-P0355

Plate, Komatsu Logo

SN: 60001-UP

3шт.

9

42A-93-51251

Decal, Warning, Lifting Operation

SN: 60001-UP

1шт.

10

09960-00601

Mark, Lift Point

SN: 60001-UP

3шт.

11

09667-03001

Plate, Caution, Rotating Object

SN: 60001-UP

1шт.

12

09161-23000

Plate, Warning, Articulation Lock

SN: 60001-UP

1шт.

13

09162-23000

Plate, Danger, Keep Off

SN: 60001-UP

2шт.

14

09651-03001

Plate, Warning, Read Manual Before Operating

SN: 60001-UP

1шт.

15

09802-33000

Plate, Warning, Before Operating and Traveling

SN: 60001-UP

1шт.

16

09653-03001

Plate, Warning, High Temperature

SN: 60001-UP

1шт.

17

42A-93-51430

Plate, Warning, Before Leaving Seat

SN: 60420-UP

1шт.

18

11Y-98-31150

Plate, Danger, Keep Away from Machine

SN: 60001-UP

2шт.

19

09807-C0883

Plate, Danger, Keep Out under Work Equipment

SN: 60001-UP

2шт.

20

235-53-31140

Plate, Warning, Battery Cables

SN: 60001-UP

1шт.

21

09842-A0481

Plate, Warning, No Jump Start

SN: 60001-UP

1шт.

22

09685-00002

Plate, Symbol, Lock/Unlock

SN: 60001-UP

1шт.

23

09668-03001

Plate, Warning, Hot Water

SN: 60001-UP

1шт.

24

09685-0000D

Plate, Symbol, Lock/Unlock

SN: 60001-UP

1шт.

25

42A-93-51380

Plate, Radiator Drain

SN: 60001-UP

1шт.

26

42A-93-51370

Plate, Hydraulic Oil

SN: 60001-UP

1шт.

27

42A-93-51350

Plate, Fuse Box

SN: 60001-62117

1шт.

28

42A-93-51360

Plate, Important, Steering Hose

SN: 60001-UP

1шт.

29

09801-13001

Plate, Danger, High Voltage Hazard

SN: 60001-UP

1шт.

30

09620-A2000

Plate, Name, ROPS/FOPS (Limited Supply)

SN: 60001-UP

1шт.

31

04418-13060

Screw

SN: 60001-UP

4шт.

32

42A-93-51161

Decal, Operating Pattern

SN: 60001-62117

1шт.

33

09664-30011

Plate, Danger, Battery

SN: 60420-UP

1шт.

34

42A-93-51720

Plate

SN: 60420-UP

1шт.

35

09845-00480

Plate, Caution, Blast Site

SN: 60925-UP

1шт.
