Артикул
Название
Примечание
Количество
|$1
363-17-31402
PUMP ASS'Y,(A4VG28DA-931-0)
SN: 21212-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-01A0B T0 Y1610-07A0B .
-1шт.
|$$3
THE UCHIDA YUATSU KIKI PART NUMBER IS THAT UC IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
1
UCBA041S9146-0
PUMP ASS'Y,PISTON
SN: 21212-UP
1шт.
2
UCH9118R7702-0
PUMP ASS'Y,GEAR
SN: 21212-UP
1шт.
3
UC1100444396
ORIFICE
SN: 21212-UP
1шт.
4
UC1100440064
HARNESS
SN: 21212-UP
1шт.
5
01252-31025
BOLT
SN: 21212-UP
2шт.
6
0
PLATE, NAME
SN: 21212-UP
1шт.
6
0
SCREW
SN: 21212-UP
2шт.
7
UC1100599083
PACKING
SN: 21423-UP
1шт.
7
UC1100456106
GASKET
SN: 21212-21422
1шт.
Выбрано товаров: 12
