Запчасти Komatsu WA480-6 H-A ГИДР. НАСОС. ЭКСТРЕНН. НАСОС РУЛЕВ. УПРАВЛ-Я ГИДРАВЛИКА

|$0

705-40-01020

PUMP ASSEMBLY, EMERGENCY STEERING

SN: A48001--UP

1шт.

1

705-40-80230

BRACKET

SN: A48001--UP

1шт.

N/I

705-41-80610

BUSHING, PLANE (DRIVE SIDE)

SN: A48001--UP

1шт.

N/I

705-40-80620

BUSHING, PLANE (DRIVEN SIDE)

SN: A48001--UP

1шт.

2

705-40-33011

CASE, GEAR

SN: A48001--UP

1шт.

3

705-40-80131

COVER

SN: A48001--UP

1шт.

N/I

705-41-80620

BUSHING, PLANE (DRIVE SIDE)

SN: A48001--UP

1шт.

N/I

705-41-80610

BUSHING, PLANE (DRIVEN SIDE)

SN: A48001--UP

1шт.

4

705-40-33411

GEAR, DRIVE

SN: A48001--UP

1шт.

5

705-40-33511

GEAR, DRIVEN

SN: A48001--UP

1шт.

6

705-40-80720

PLATE, SIDE

SN: A48001--UP

2шт.

7

705-40-80760

SEAL, RING

SN: A48001--UP

2шт.

8

705-40-80810

SEAL, OIL

SN: A48001--UP

1шт.

9

705-40-80870

PLATE

SN: A48001--UP

1шт.

10

04065-03515

RING, SNAP

SN: A48001--UP

1шт.

11

705-41-80930

BOLT

SN: A48001--UP

4шт.

12

01643-51232

WASHER

SN: A48001--UP

4шт.

13

04020-00820

PIN, DOWEL

SN: A48001--UP

4шт.

|$18

18

-1шт.

|$19

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

19

-1шт.
