Запчасти Komatsu WA480-6 H-9A ГИДР. НАСОС. ВЕНТИЛЯТОР (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-07A0)

SN: A48001--UP

1шт.

|$1

PUMP SUBASSEMBLY (SEE FIG. H0210-07A0)

SN: A48001--UP

1шт.

|$2

708-1S-03340

VALVE ASSEMBLY

SN: A48001--UP

1шт.

|$3

708-1S-03920

BODY SUBASSEMBLY

SN: A48001--UP

1шт.

1

NSS

BODY

SN: A48001--UP

1шт.

2

NSS

PLUG

SN: A48001--UP

3шт.

3

708-1S-15420

PISTON

SN: A48001--UP

1шт.

4

708-1S-15430

SLEEVE

SN: A48001--UP

1шт.

5

07002-21623

O-RING

SN: A48001--UP

1шт.

6

07000-B1010

O-RING

SN: A48001--UP

1шт.

7

708-1S-15230

SPOOL

SN: A48001--UP

1шт.

8

708-1S-15240

SEAT

SN: A48001--UP

1шт.

9

708-1S-15440

SPRING

SN: A48001--UP

1шт.

10

723-56-31630

PLUG

SN: A48001--UP

1шт.

11

07002-21623

O-RING

SN: A48001--UP

1шт.

12

708-1S-15270

LEVER

SN: A48001--UP

1шт.

13

708-1S-15250

RETAINER

SN: A48001--UP

1шт.

14

708-1S-15280

SPACER

SN: A48001--UP

1шт.

15

708-1S-15260

PLUG

SN: A48001--UP

1шт.

16

07002-21023

O-RING

SN: A48001--UP

1шт.

17

20B-27-11210

BLEEDER

SN: A48001--UP

1шт.

18

07040-11007

PLUG

SN: A48001--UP

2шт.

19

07002-21023

O-RING

SN: A48001--UP

2шт.

20

01252-60635

BOLT

SN: A48001--UP

2шт.

21

702-21-57700

PILOT VALVE

SN: A48001--UP

1шт.

22

702-21-55880

O-RING

SN: A48001--UP

1шт.

23

702-21-55890

O-RING

SN: A48001--UP

2шт.

|$27

27

-1шт.

|$28

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

28

-1шт.
