Запчасти Komatsu WA480-6 H-8A ГИДР. НАСОС. ВЕНТИЛЯТОР (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-07A0)

SN: A48001--UP

-1шт.

|$1

PUMP SUBASSEMBLY (SEE FIG. H0210-07A0)

SN: A48001--UP

-1шт.

1

708-1S-12320

SHAFT

SN: A48001--UP

1шт.

2

706-73-40890

BEARING

SN: A48001--UP

1шт.

3

708-1S-12260

BEARING

SN: A48001--UP

1шт.

4

708-7T-05020

SPACER KIT

SN: A48001--UP

1шт.

|$6

NSS

SPACER, 1.6 MM

SN: A48001--UP

1шт.

|$7

NSS

SPACER, 1.7 MM

SN: A48001--UP

1шт.

|$8

NSS

SPACER, 1.8 MM

SN: A48001--UP

1шт.

|$9

NSS

SPACER, 1.9 MM

SN: A48001--UP

1шт.

|$10

NSS

SPACER, 2.0 MM

SN: A48001--UP

1шт.

|$11

NSS

SPACER, 2.1 MM

SN: A48001--UP

1шт.

|$12

NSS

SPACER, 2.2 MM

SN: A48001--UP

1шт.

5

708-1S-12280

RING, WIRE

SN: A48001--UP

1шт.

6

708-1S-12330

RETAINER

SN: A48001--UP

1шт.

7

708-1S-12340

CASE

SN: A48001--UP

1шт.

8

708-1T-11880

SEAL, OIL

SN: A48001--UP

1шт.

9

207-09-11140

O-RING

SN: A48001--UP

1шт.

10

04065-06220

RING

SN: A48001--UP

1шт.

11

708-1S-13130

BLOCK, CYLINDER

SN: A48001--UP

1шт.

12

708-1S-13450

PLATE, VALVE

SN: A48001--UP

1шт.

13

708-3S-13160

WASHER

SN: A48001--UP

2шт.

14

708-3S-13150

SPRING

SN: A48001--UP

1шт.

15

04065-03515

RING, SNAP

SN: A48001--UP

1шт.

16

708-1S-13370

GUIDE, RETAINER

SN: A48001--UP

1шт.

17

708-1S-13380

PIN

SN: A48001--UP

3шт.

18

708-1S-13360

RETAINER, SHOE

SN: A48001--UP

1шт.

19

708-1S-13320

PISTON SUBASSEMBLY

SN: A48001--UP

7шт.

20

708-1S-14210

PLUG

SN: A48001--UP

1шт.

21

708-3S-14261

PLUG

SN: A48001--UP

1шт.

22

07002-11223

O-RING

SN: A48001--UP

2шт.

23

708-1S-14230

PISTON SUBASSEMBLY

SN: A48001--UP

1шт.

24

708-1S-14241

SPRING

SN: A48001--UP

1шт.

|$33

33

-1шт.

|$34

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

34

-1шт.
