Запчасти Komatsu WA480-6 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-01A0)

SN: A48001--UP

-1шт.

1

702-21-57700

VALVE, PILOT

SN: A48001--UP

1шт.

2

702-21-55880

O-RING

SN: A48001--UP

1шт.

3

702-21-55890

O-RING

SN: A48001--UP

2шт.

4

01252-60635

BOLT

SN: A48001--UP

2шт.

5

708-2G-15650

PLUG

SN: A48001--UP

1шт.

6

07000-B1008

O-RING

SN: A48001--UP

1шт.

7

07001-01008

RING, BACK-UP

SN: A48001--UP

2шт.

8

07002-61423

O-RING

SN: A48001--UP

1шт.

9

01643-51232

WASHER

SN: A48001--UP

1шт.

10

01010-81220

BOLT

SN: A48001--UP

1шт.

11

08193-21012

CLIP

SN: A48001--UP

1шт.

|$12

708-2G-03810

VALVE, SHUTTLE

SN: A48001--UP

1шт.

12

07002-21423

O-RING

SN: A48001--UP

1шт.

13

720-2M-15412

SLEEVE

SN: A48001--UP

1шт.

14

720-2M-15421

HOLDER

SN: A48001--UP

1шт.

15

720-2M-15430

SEAL

SN: A48001--UP

1шт.

16

700-84-11730

BALL

SN: A48001--UP

1шт.

17

720-2M-15440

SEAL

SN: A48001--UP

1шт.

|$19

19

-1шт.

|$20

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

20

-1шт.
