Запчасти Komatsu WA480-6 H-7A ГИДР. НАСОС. ГИДРОТРАНСФОРМАТОР (/) ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H0210-16A0)

SN: A47001--UP

1шт.

|$1

705-33-30540

PUMP ASSEMBLY, (SAL32)

SN: A47001--UP

1шт.

1

705-19-01521

BRACKET

SN: A47001--UP

1шт.

N/I

705-17-03151

BUSHING, PLANE

SN: A47001--UP

2шт.

2

705-18-30110

CASE, GEAR

SN: A47001--UP

1шт.

3

705-17-01121

COVER

SN: A47001--UP

1шт.

N/I

705-17-01351

BUSHING, PLANE

SN: A47001--UP

2шт.

4

705-18-30750

GEAR, DRIVE

SN: A47001--UP

1шт.

5

705-18-30810

GEAR, DRIVEN

SN: A47001--UP

1шт.

6

705-17-01610

PLATE, SIDE

SN: A47001--UP

2шт.

7

705-67-01470

SEAL, OIL

SN: A47001--UP

2шт.

8

705-67-01440

RING, BACK-UP

SN: A47001--UP

2шт.

9

04020-00820

PIN, DOWEL

SN: A47001--UP

4шт.

10

04020-01228

PIN, DOWEL

SN: A47001--UP

2шт.

11

705-67-01380

O-RING

SN: A47001--UP

2шт.

12

01253-61200

BOLT

SN: A47001--UP

4шт.

13

01643-51232

WASHER

SN: A47001--UP

4шт.

14

705-17-03381

O-RING

SN: A47001--UP

1шт.

15

01252-61445

BOLT

SN: A47001--UP

4шт.

16

705-17-04980

WASHER

SN: A47001--UP

4шт.

17

705-17-01880

PLATE

SN: A47001--UP

1шт.

18

07000-E3032

O-RING

SN: A47001--UP

1шт.

19

01010-81025

BOLT

SN: A47001--UP

4шт.

20

01643-51032

WASHER

SN: A47001--UP

4шт.

|$24

24

-1шт.

|$25

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

25

-1шт.
