Запчасти Komatsu WA480-6 H-A ГИДР. НАСОС. ГИДРОТРАНСФОРМАТОР (/) ГИДРАВЛИКА

|$0

705-51-30820

PUMP ASSEMBLY, (SAL80+32)

SN: A47001--UP

1шт.

|$1

705-33-38260

PUMP ASSEMBLY, (SAL80)

SN: A47001--UP

1шт.

1

705-18-03580

BRACKET ASSEMBLY

SN: A47001--UP

1шт.

N/I

705-17-03352

BUSHING, PLANE

SN: A47001--UP

2шт.

2

705-17-38010

CASE, GEAR

SN: A47001--UP

1шт.

3

705-17-03221

CARRIER ASSEMBLY

SN: A47001--UP

1шт.

N/I

705-17-03352

BUSHING, PLANE

SN: A47001--UP

2шт.

4

705-19-38720

GEAR, DRIVE

SN: A47001--UP

1шт.

5

705-17-38511

GEAR, DRIVEN

SN: A47001--UP

1шт.

6

705-17-03630

PLATE, SIDE

SN: A47001--UP

1шт.

7

705-17-03640

PLATE, SIDE

SN: A47001--UP

1шт.

8

705-17-03443

RING, BACK-UP

SN: A47001--UP

2шт.

9

705-17-03473

SEAL

SN: A47001--UP

2шт.

10

705-17-03381

O-RING

SN: A47001--UP

2шт.

11

04020-01228

PIN, DOWEL

SN: A47001--UP

4шт.

12

01253-61615

BOLT

SN: A47001--UP

4шт.

13

01643-51645

WASHER

SN: A47001--UP

4шт.

14

705-17-03870

PLATE

SN: A47001--UP

1шт.

15

705-17-03811

SEAL, OIL

SN: A47001--UP

2шт.

16

04065-05220

RING, SNAP

SN: A47001--UP

1шт.

17

705-19-01330

COUPLING

SN: A47001--UP

1шт.

|$21

21

-1шт.

|$22

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

22

-1шт.
