Запчасти Komatsu WA480-6 H-A ГИДР. НАСОС. РУЛЕВ. УПРАВЛЕНИЕ (/) ГИДРАВЛИКА

|$0

708-1W-00010

PUMP ASSEMBLY

SN: A47001--UP

1шт.

|$1

708-1W-01012

PUMP SUBASSEMBLY

SN: A47001--UP

1шт.

|$2

708-1W-04921

CASE ASSEMBLY

SN: A47001--UP

1шт.

1

NSS

CASE, PUMP

SN: A47001--UP

1шт.

2

NSS

PLUG

SN: A47001--UP

5шт.

3

708-1W-44311

SLEEVE

SN: A47001--UP

1шт.

4

708-1W-44220

RING

SN: A47001--UP

1шт.

5

708-8E-16160

PLUG

SN: A47001--UP

1шт.

6

07002-11023

O-RING

SN: A47001--UP

1шт.

7

07040-11409

PLUG

SN: A47001--UP

1шт.

8

07002-11423

O-RING

SN: A47001--UP

1шт.

9

706-73-42370

O-RING

SN: A47001--UP

1шт.

10

07000-B1009

O-RING

SN: A47001--UP

1шт.

11

04020-01024

PIN

SN: A47001--UP

1шт.

12

01010-61470

BOLT

SN: A47001--UP

4шт.

13

01643-31445

WASHER

SN: A47001--UP

4шт.

14

708-1W-41010

CAP, END

SN: A47001--UP

1шт.

15

708-1W-42120

BEARING

SN: A47001--UP

1шт.

16

708-3T-13421

BALL

SN: A47001--UP

2шт.

17

708-1W-43412

CAM, ROCKER

SN: A47001--UP

1шт.

18

04260-01270

BALL

SN: A47001--UP

1шт.

19

708-1U-12120

SHAFT

SN: A47001--UP

1шт.

20

708-1W-42110

BEARING

SN: A47001--UP

1шт.

21

708-1U-12320

CASE, SEAL

SN: A47001--UP

1шт.

22

708-1W-42130

SEAL, OIL

SN: A47001--UP

1шт.

23

07000-B2065

O-RING

SN: A47001--UP

1шт.

24

708-1W-05810

SPACER KIT

SN: A47001--UP

1шт.

|$27

NSS

SPACER, 1.6 MM

SN: A47001--UP

1шт.

|$28

NSS

SPACER, 1.7 MM

SN: A47001--UP

1шт.

|$29

NSS

SPACER, 1.8 MM

SN: A47001--UP

1шт.

|$30

NSS

SPACER, 1.9 MM

SN: A47001--UP

1шт.

|$31

NSS

SPACER, 2.0 MM

SN: A47001--UP

1шт.

|$32

NSS

SPACER, 2.1 MM

SN: A47001--UP

1шт.

|$33

NSS

SPACER, 2.2 MM

SN: A47001--UP

1шт.

25

04065-07225

RING

SN: A47001--UP

1шт.

|$35

35

-1шт.

|$36

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

36

-1шт.
