Артикул
Название
Примечание
Количество
|$14
421-926-0401
ROPS CAB ASS'Y,(MONOCOQUE)
SN: 85149-UP
1шт.
|$15
421-926-0400
ROPS CAB ASS'Y,(MONOCOQUE)
SN: 85001-85148
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A0 AND K0210-46A0.
-1шт.
|$17
421-926-0501
ROPS CAB ASS'Y,(MONOCOQUE+SASH WINDOW)
SN: 85149-UP
1шт.
|$18
421-926-0500
ROPS CAB ASS'Y,(MONOCOQUE+SASH WINDOW)
SN: 85001-85148
1шт.
|$$6
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A1 AND K0210-46A0, K0210-47A1.
-1шт.
|$20
421-926-0600
ROPS CAB ASS'Y,(MONOCOQUE+FIX WINDOW+A-A/C)
SN: 90001-UP
1шт.
|$$8
THIS ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A1 AND K0210-46A0.
-1шт.
|$23
423-926-4500
FRONT COVER ASS'Y
SN: 85001-UP
1шт.
1
0
FRONT COVER
SN: 85001-UP
1шт.
2
423-07-31641
SHEET
SN: 85001-UP
2шт.
3
423-07-31661
SHEET
SN: 85001-UP
2шт.
5
01225-70620
SCREW
SN: 85001-UP
10шт.
6
23S-55-51970
WASHER
SN: 85001-UP
10шт.
7
426-56-31890
COLLAR
SN: 85001-UP
10шт.
8
426-56-31870
WASHER
SN: 85001-UP
10шт.
9
421-925-3170
CUSHION
SN: 85001-UP
1шт.
10
423-06-45410
SWITCH,MONITOR PANEL MODE (1)
SN: 85001-UP
1шт.
11
423-06-45390
SWITCH,MONITOR PANEL MODE (2)
SN: 85001-UP
1шт.
16
423-06-45370
SWITCH,PARKING BRAKE
SN: 85001-UP
1шт.
17
423-06-45440
SWITCH,HEAT GLASS, REAR
SN: 85001-UP
1шт.
19
09415-00506
CAP
SN: 85001-UP
1шт.
20
423-926-4562
SUPPORT
SN: 85001-UP
1шт.
Выбрано товаров: 33
