Запчасти Komatsu WA480-6 КАБИНА ROPS (MARK) (MONOCOQUE ТИП)(№8-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$14

421-926-0401

ROPS CAB ASS'Y,(MONOCOQUE)

SN: 85149-UP

1шт.

|$15

421-926-0400

ROPS CAB ASS'Y,(MONOCOQUE)

SN: 85001-85148

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A0 AND K0210-46A0.

-1шт.

|$17

421-926-0501

ROPS CAB ASS'Y,(MONOCOQUE+SASH WINDOW)

SN: 85149-UP

1шт.

|$18

421-926-0500

ROPS CAB ASS'Y,(MONOCOQUE+SASH WINDOW)

SN: 85001-85148

1шт.

|$$6

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A1 AND K0210-46A0, K0210-47A1.

-1шт.

|$20

421-926-0600

ROPS CAB ASS'Y,(MONOCOQUE+FIX WINDOW+A-A/C)

SN: 90001-UP

1шт.

|$$8

THIS ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A1 AND K0210-46A0.

-1шт.

1

417-926-3711

PLATE,KOMATSU

SN: 85001-UP

1шт.

2

09970-00230

PLATE,GALEO

SN: 85001-85343

2шт.

3

425-93-51110

DECAL,EMERGENCY EXIT

SN: 85001-UP

1шт.

4

421-926-4990

PLATE,EMERGENCY ESCAPE DOOR

SN: 85374-UP

1шт.

4

0

PLATE,EMERGENCY ESCAPE DOOR

SN: 85001-85373

1шт.
