Запчасти Komatsu WA480-6 ТРАНСМИССИЯ (1 И 4 МУФТА)(№8-9) СИЛОВАЯ ПЕРЕДАЧА

|$12

714-07-30004

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$13

714-07-30001

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$14

714-07-30000

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$4

THESE ASSEMBLIES CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0 TO F4350-64A0.

-1шт.

|$16

714-07-30014

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$17

714-07-30011

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$18

714-07-30010

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$8

THESE ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A0, 52A1, 53A0 TO 61A0, 58A1, 59A1, 62A1 TO 64A1.

-1шт.

|$20

714-07-30024

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$21

714-07-30021

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$22

714-07-30020

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$12

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A2 TO F4350-64A0.

-1шт.

|$24

714-07-30034

TRANSMISSION ASS'Y

SN: 85366-90000

1шт.

|$25

714-07-30031

TRANSMISSION ASS'Y

SN: 85165-85365

1шт.

|$26

714-07-30030

TRANSMISSION ASS'Y

SN: 85001-85164

1шт.

|$$16

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F4350-51A2 TO F4350-64A1.

-1шт.

|$49

714-07-32022

CLUTCH

SN: 85001-90000

1шт.

1

714-07-32122

SHAFT AND CYLINDER A,1ST AND 4TH

SN: 85001-90000

1шт.

1

0

SHAFT,UPPER

SN: 85001-90000

1шт.

1

0

ORIFICE

SN: 85001-90000

1шт.

1

0

SCREW

SN: 85001-90000

2шт.

1

0

HOUSING

SN: 85001-90000

1шт.

2

714-07-22661

PISTON,RANGE

SN: 85001-90000

2шт.

3

714-12-19711

DISC

SN: 85001-90000

15шт.

4

714-16-19730

PLATE,SEPARATE

SN: 85001-90000

17шт.

5

56D-15-12710

SPRING,WAVE

SN: 85001-90000

15шт.

6

714-12-12610

PLATE,END

SN: 85001-90000

2шт.

7

419-15-12140

RING,SNAP

SN: 85001-90000

2шт.

8

714-16-19220

RING,SEAL (K1)(K3)

SN: 85001-90000

2шт.

9

714-07-19320

RING,SEAL (K1)(K3)

SN: 85001-90000

2шт.

10

714-08-19570

WASHER,THRUST

SN: 85001-90000

3шт.

11

714-08-19560

WASHER,THRUST

SN: 85001-90000

1шт.

12

714-23-19410

BEARING

SN: 85001-90000

2шт.

13

714-23-19430

BEARING

SN: 85001-90000

1шт.

14

714-11-12720

SPACER

SN: 85001-90000

1шт.

15

714-07-22550

SNAP RING,SNAP (K1)(K3)

SN: 85001-90000

1шт.

16

714-07-22442

GEAR, 64 TEETH,4TH

SN: 85001-90000

1шт.

17

714-07-32432

GEAR, 23 TEETH,1ST

SN: 85001-90000

1шт.

18

714-07-22512

GEAR, 36 TEETH,2ND

SN: 85001-90000

1шт.

19

714-12-19340

BEARING,ROLLER

SN: 85001-90000

2шт.

20

419-15-12122

RING,SEAL (K1)(K3)

SN: 85001-90000

3шт.
